Playing Along With A Song
Notation Screen
When the power of the HPi-7 is turned on, a notation screen like the following will appear in the
display.
This can display not only the onboard songs, but also the notation for SMF music files or a performance
that you’ve recorded on the HPi-7.
fig.notation-e
* If you have selected a part that contains no performance data, the notation will not show any notes. To change the
part that is displayed, refer to “Changing the Notation Screen Settings” (p. 47).
* The fingering numbers shown in the screen indicate one possible fingering.
* The fingering numbers can be displayed only when playing some internal song.
Some notes on the notation screen
• When you begin song playback, the notation screen will show . While this symbol is displayed,
performance data is being loaded from floppy disk or internal memory. It may take dozens to
read the data. Please wait.
• The displayed notation is generated from the music files, and priority is given to making the
display easy to read rather than reproducing a complicated or difficult performance accurately.
For this reason, you may notice differences when compared with commercially available sheet
music. In particular, this is not suitable for display of sophisticated or complex songs that require
detailed notations.
• In the notation screen, lyrics or notes may fall outside the display range of the screen, and fail to
be shown.
• If you display the notation or change the displayed part during song playback, the song may
sometimes play back from the beginning.
Lyrics
When playing back song data that contains lyric data,
the lyrics will be displayed if you check this.
This item cannot be selected if there is no lyric data.
Pedal
When “Replay” is selected, you can start and stop
playback of the song data by pressing the left pedal (p. 56).
When “PageTurn” is selected, you can turn the pages of
the score by pressing the pedals. Press the center pedal to
turn to the next page in the score, and press the left pedal
to turn to the previous page.
Keyboard
The keyboard will be displayed
under the notation if you check this.
Fingering
When playing back song data that includes fingering
numbers, the fingering numbers will be displayed if
you check this. This is convenient when you want to
practice the correct fingering.
The fingers are numbered as follows: 1: thumb, 2: index
finger, 3: middle finger, 4: ring finger, 5: little finger.
This item cannot be selected if there is no fingering
data.
Part
Select the part(s) for which
the notation will be displayed.
: Notation for both hands
: Right-hand notation only
: Left-hand notation only
: Notation of the specified part
(→ to change the part, see p. 47)
Tempo Song name Beat Measure
Chord
When playing back song data that
contains chord data, the chord name
will be displayed if you check this.
This item cannot be selected if there
is no chord data.
Select the item to set
Change the setting
Close, open the menu
For details refer to p. 47
