Hardware Functional Overview

(Low byte) registers if the system wants to read data from PMU08.

Features Summary of the Micro-P:

• 5 channels 8-bit analog to digital converter

• Timer0: 8-bit tuner/counter with 8-bit prescaler

• Timer1: 16-bit timer/counter. TMR1 can be incremented during sleep via external

crystal/clock

• Timer2: 8-bit timer/counter with 8-bit period register, prescaler and postscaler

• Capture, Compare, PWM module

• Synchronous Serial port (SSP) with SPI and I

2

C

• Universal Synchronous Asynchronous Receiver Transmitter (USART/SCI)

• Brown-out detection circuitry for Brown-out Reset (BOR)

• 2K bytes program memory

• 128 bytes data memory

• 22 I/O pin

• 8 interrupt sources

FIC M295 / M296 Service Manual 4-23
