Outline of the M295 / M296
NumLock:
[On] / [Off]
Selects Power-on state for NumLock
TV System
[NTSC] / [PAL]
Switch TV System Mode
Sub-System Select
[Normal PAL TV] / [PAL –M]
/ [PAL-N]
PAL TV Sub-System select
PS/2 Mouse
[Disabled] / [Both] / [Auto] [Disabled] prevents any installed PS/2
mouse from functioning, but frees up
IRQ12. [Both] allows both internal and
external PS/2 mouse to be active.
[Auto] will enable the PS/2 mouse only
if present.
LCD Panel View
Expansion:
[Disabled] / [Enabled] [Disabled] – Reduces the panel view in
some video mode
[Enabled] – Expands the panel view,
but it may adversely affect the
graphic/text quality
Embedded Share
Memory
[8MB] / [16MB] / [32MB] /
[64MB]
Embedded Share Memory size for AGP
VGA memory.
Graphics Aperture:
[4MB] / [8MB] / [16MB] /
[32MB] / [64MB] [128MB] /
[256MB]
Select the size of the Graphics Aperture
for the AGP video device.
EmbedDed Audio
Device
[Enabled] / [Disabled] Enabled or Disabled SiS Embeded
Audio ( SiS 7018 AC97 Audio )
Summary screen:
[Disable] / [Enabled]
Display system configuration on boot
4I/O Device
Configuration
Submenu Peripheral Configuration
Num-Lock on Boot – Allows you to set the power-on state for the <NumLock>
key. Set this to [LockOn] if you want to enable <NumLock> during power on.
TV System – [PAL] for the most of TV in Europe region and China. [NTSC]
for the most of TV in North America, Japan,
& Taiwan.
Sub-System Select – [Normal PAL TV] for standard PAL TV of the
country in Europe region. [PAL-M] for PAL standard TV especially in Brazil
country. [PAL-N] for standard PAL TV especially in Argentina country.
PS/2 Mouse – [Disabled] prevents any installed PS/2 mouse from functioning,
but frees up IRQ12. [Both] allows both internal and external PS/2 mouse to be
active. [Auto] will only allow the external PS/2 mouse to be active if it is detected.
LCD Panel View Expansion – [Disabled] – Reduces the panel view in some
video mode. [Enabled] - Expands the panel view, but it may adversely affect the
graphic/text quality.
Embedded Share Memory – [8MB] [16MB] [32MB] [64MB] – Embedded
Share Memory AGP VGA Memory Size.
Graphics Aperture - [4MB] [8MB] [16MB][32MB] [64MB] [128MB]
[256MB] – Select the size of the Graphics Aperture for the AGP video device.
1-24 FIC M295 / M296 Service Manual
