PPrreeccaauuttiioonnss
Follow standard ESD precautions. Turn power off before connecting the sensor.
Do not touch the electrical pins without static protection such as a grounded wrist strap.
Do not touch the glass scale unless you are wearing talc-free gloves or finger cots.
Please read this installation manual for full instructions.
MicroE Systems Mercury series reflective encoders are classified as CDRH Class I and IEC Class 1M laser products.
• Invisible laser radiation (wavelength: 850 nm). Max power 1.5 mW CW.
• This product conforms to all applicable standards under 21 CFR Ch. I 1040.10.
• CDRH Class I level of laser radiation is not considered to be hazardous.
• CAUTION - The use of optical instruments with this product will increase eye hazard.
•
DO NOT VIEW DIRECTLY WITH OPTICAL INSTRUMENTS
(MICROSCOPES, EYE LOUPES OR MAGNIFIERS)
• CLASS 1M LASER PRODUCT
• IEC 60825-1 (2001)
Safety Information
1
2
PPaatteennttss
Covered by the following patents: US 5,991,249; EP 895,239; JP 3,025,237; US 6,897,435; and EP 1,451,933.
Additional patents and patents pending may apply.
TTaabbllee OOff CCoonntteennttss
SYSTEM ILLUSTRATION PAGE
Encoder with Linear scale 2
Encoder with Rotary scale 3
INSTALLATION INSTRUCTIONS
Encoder System Mounting - Linear 4
Encoder System Alignment - Linear 5
Centering the Index & Calibration - Linear 5
Encoder System Mounting - Rotary 6
Encoder System Alignment - Rotary 7
Centering the Index & Calibration - Rotary 7
REFERENCE SECTION
Installation of Linear Scales 8
Grounding Instructions 9
Recommendations for Power 9
Customer Interface Cable Requirements 10
Serial Output Specifications 11-12
SMARTPRECISION SOFTWARE INSTALLATION 13-19
SPECIFICATIONS
Operating and Electrical 20
Output Connector Pinout 20
Serial Output 21
Operational Modes: Standard Communication 21
Serial Output Specificattion 22
Operational Modes - Trigger Approach Diagram 23
Serial Data Format 24
ENCODER TROUBLESHOOTING
Selected Topics 24
Cleaning Scales 25
Contact MicroE Systems Back Cover
