19 EUROPOWER PMP1000/PMP4000/PMP6000 User Manual
Specifications6.
PMP1000
Microphone Inputs
Type XLR, electronically balanced input circuit
Mic E.I.N. (20 Hz - 20 kHz)
@ 0 Ohm -134 dB / 136 dB A-weighted
source resistance
@ 50 Ohm -131.5 dB / 134 dB A-weighted
source resistance
@ 150 Ohm -129 dB / 155 dB A-weighted
source resistance
Frequency response < 10 Hz - 200 kHz (-1 dB)
< 10 Hz - > 200 kHz (-3 dB)
Gain +10 dB, +60 dB
Max. input level +12 dBu @ +10 dB gain
Impedance approx. 2.6 kOhm balanced
approx. 1.3 kOhm unbalanced
Signal-to-noise ratio 109 dB / 112 dB A-weighted
(0 dBu In @ +10 dB gain)
Noise (THD + N) 0.002% / 0.0018% A-weighted
Mono Line Inputs
Type ¼" TS connectors, balanced
Impedance approx. 20 kOhm
Max. input level +21 dBu
Equalizer
Low 80 Hz / +/-15 dB
Mid 2.5 kHz / +/-15 dB
High 12 kHz / +/-15 dB
2 Track Input
Type RCA
Impedance approx. 3.6 kOhm
Preamp Outputs
MAIN
Type ¼" TRS connectors, unbalanced
Impedance approx. 150 Ohm, unbalanced
Max. output level +21 dBu
Monitor
Type ¼" TRS connectors, unbalanced
Impedance approx. 150 Ohm, unbalanced
Max. output level +21 dBu
Stereo Outputs
Type RCA
Impedance approx. 1 kOhm
Max. input level +21 dBu
Loudspeaker Outputs
Type Professional locking connector
Load impedance:
MAIN L/R 4 - 8 Ohm
MONITOR/MAIN MONO 4 - 8 Ohm
MAIN MONO/MAIN MONO 4 - 8 Ohm
BRIDGE 8 - 16 Ohm
DSP
Converter 24-bit Delta-Sigma, 64/128-times oversampling
Dynamics D/A 90 dB
Sampling rate 46.875 kHz
Delay Time max. 5 secs
Signal run time approx. 1.5 ms
(Line In > Line Out)
Display
Type 2-digit, 7 segment LED
Output Power
RMS @ 1% THD, both channels driven:
8 Ohm per channel 90 W
4 Ohm per channel 130 W
RMS @ 1% THD, bridged mode:
8 Ohm 200 W
Peak Power, both channels driven:
8 Ohm per channel 135 W
4 Ohm per channel 250 W
Peak Power, bridged mode:
8 Ohm 500 W
