The Singing Machine SMG-151 Karaoke Machine User Manual



13 1412
2
3
4
6
1
7
8
9
10
5
11
15
SMG-151
16
17
18
21
22
23
24
19
20
25
26
27
E5
CONTROL LOCATIONS
1. ON/OFF LED
2. FUNCTION SELECTOR
(CDG/RADIO/AUX/OFF)
4. MASTER VOLUME control
5. Loudspeaker
6. PROGRAM button
7. REPEAT button
8. AUDIO button
9. AUTO VOICE CONTROL (A.V.C.) button
10. MP3/JPG button
11. DISPLAY button
12. ECHO/KEY - button
13. ECHO/KEY button
14.
15. LCD display
16. Handle
17. FM (ST.) indicator
18. BAND selector
19. Antenna
20. Tuning knob
21. -10 tracks button
22. +10 tracks button
23. PLAY/PAUSE button
24. SKIP button
25. STOP button
26. SKIP button
27. Model number
3. MIC VOLUME control
ECHO/KEY + button
28. AUDIO IN (R) jack
29. Headphone jack
30. MIC 1 jack
31. MIC 2 jack
32. AUDIO OUT (R) jack
33. AUDIO OUT (L) jack
34. VIDEO OUT jack
35. AC jack
36. AUDIO IN (L) jack
TOP VIEW
REAR VIEW
2928 30 3132 33 34 35 36
ENGLISH
