01X Owner’s Manual
115
Appendix
Parameter Lists
■ Preset EQ Library
21 A. G. Stroke 2
A variation on preset 20. You can also use it with an
acoustic-electric nylon string guitar.
22 A. G. Arpeg. 1 Ideal for arpeggio playing on acoustic guitars.
23 A. G. Arpeg. 2 A variation on preset 22.
24 Brass Sec.
Use with trumpets, trombones, or saxes. When used
with a single instrument, try adjusting the HIGH or
HIGH-MID frequency.
25 Male Vocal 1
An EQ template for male vocals. Try adjusting the
HIGH or HIGH-MID parameters according to the
voice quality.
26 Male Vocal 2 A variation on preset 25.
27 Female Vo. 1
An EQ template for female vocals. Try adjusting the
HIGH or HIGH-MID parameters according to the
voice quality.
28 Female Vo. 2 A variation on preset 27.
29 Chorus&Harmo An EQ template for brightening choruses.
30 Total EQ 1
Use on a stereo mix during mixdown. Sounds even
better when used with a compressor.
31 Total EQ 2 A variation on preset 30.
32 Total EQ 3
A variation on preset 30. Can also be used with
paired Input or Output Channels.
33 Bass Drum 3
A variation on preset 1, with low and mid range
reduced.
34 Snare Drum 3 A variation on preset 3, creating a thicker sound.
35 Tom-tom 2
A variation on preset 5, emphasizing the mid and
high ranges.
36 Piano 3 A variation on preset 13.
37 Piano Low
Emphasizes the low range of pianos recorded in ste-
reo.
38 Piano High
Emphasizes the high range of pianos recorded in
stereo.
39 Fine-EQ Cass Add clarity when recording to or from cassette tape.
40 Narrator Ideal for recording narration.
No. Preset Name Description
No. Preset Name Description
1 Bass Drum 1
Emphasizes the low range of a bass drum and the
attack created by the beater.
2 Bass Drum 2
Creates a peak around 80 Hz, producing a tight, stiff
sound.
3 Snare Drum 1 Emphasizes “snappy” and rimshot sounds.
4 Snare Drum 2
Emphasizes various ranges for that classic rock
snare drum sound.
5Tom-tom 1
Emphasizes the attack of tom-toms, and creates a
long, “leathery” decay.
6 Cymbal
Emphasizes the attack of crash cymbals, extending
the “sparkling” decay.
7 High Hat
Use on a tight high-hat, emphasizing the mid to high
range.
8Percussion
Emphasizes attack and adds clarity to the high-
range of instruments, such as shakers, cabasas,
and congas.
9E. Bass 1
Produces a tight electric bass sound by cutting very
low frequencies.
10 E. Bass 2
Unlike preset 9, this preset emphasizes the low
range of an electric bass.
11 Syn. Bass 1 Use on a synth bass with emphasized low range.
12 Syn. Bass 2 Emphasizes the attack that is peculiar to synth bass.
13 Piano 1 Makes pianos sound brighter.
14 Piano 2
Used in conjunction with a compressor, this preset
emphasizes the attack and low range of pianos.
15 E. G. Clean
Use for line-level recording of an electric or semi-
acoustic guitar to get a slightly harder sound.
16 E. G. Crunch 1
Adjusts the tonal quality of a slightly distorted guitar
sound.
17 E. G. Crunch 2 A variation on preset 16.
18 E. G. Dist. 1 Makes a heavily distorted guitar sound clearer.
19 E. G. Dist. 2 A variation on preset 18.
20 A. G. Stroke 1 Emphasizes the bright tones of acoustic guitars.
