PROGRAM
PLAYBACK CONTROL(PBC)
TITLE
PUBLIC ADDRESS - CONNECT GUITAR
AND KEYBOARD
The user can control the playback order as desired by
using this function. This unit is equipped with 20
programs. After pressing the PROGRAM button on
the remote control or on the unit, the TV screen will
display as follows:
Use the cursor to select the first entry (i.e. 01), press
the number buttons such as “0” and “5”
Programming can only be performed prior to
choosing the “Start” option. If “Start” option is chosen,
“program play” will start and the order of playback in
the programming can not be edited. Pressing the
PROGRAM button during “program play” will display
the listing below:
Choosing the “Stop” option or pressing the STOP
button will cancel the programming immediately and
normal playback will continue.
:
1. To clear the program one by one, press the cursor
or button to select the chapter/track number.
Then press the CLEAR button.
2. This function is not available for MP3 and JPG
picture CD discs.
3. Pressing DISPLAY button during “Program Play”,
the following will display the following:
For DVD disc:
Chapter Elapsed Chapter Remain Display Off
For CDG and CD discs:
Single Elapsed Single Remain Display Off
4. The GOTO function is not available in “Program
Play” mode.
5. The programming interface of the program
function of CDG and CD are similar to the DVD.
The main difference is the input parameter of DVD
is the index of title/chapter, the input parameter of
CD is the index of track.
This function only works for video discs. User can
access a specific chapter by entering the chapter
number through the number buttons (0-9, +10) on the
remote control.
This function is only available for the disc that are
recorded with the title menu such as DVD. Pressing
TITLE button on the remote control can go back to the
title menu directly. “ROOT” will display on LCD
display. The content of the title menu is different from
disc to disc. Using the CURSOR and ENTER buttons
to select the operation as you desired.
1. Connect the guitar or keyboard to guitar input jack
or keyboard input jack.
2. Press the STANDBY button to turn the unit on.
3. The sensitivity and loudness could be adjusted as
required by turning the guitar or keyboard volume
control and/or the master volume control
this will
automatically go to the next entry (i.e. 02).
NOTE
OTHER FUNCTIONS
BASIC OPERATION
