Chapter 10 Using MIDI
Chapter 10
Setting the Program Change Map
When switching patches using Program Change messages
transmitted by an external MIDI device, you can freely set
the correspondence between Program Change messages
received by the GT-6B and the patches to be switched to in
the “Program Change Map.”
Initial Program Change Map Settings
The Program Change Map set at the factory is shown below.
Procedure
fig.10-24
1. Press [UTILITY], then press PARAMETER [ ]
[ ] so that “MIDI Map Select” is displayed.
fig.10-25
2. Rotate the PATCH/VALUE dial to select “Prog.”
* You cannot set the Program Change Map when “Fix” is
selected (it is not displayed).
* See the following item for more on “MIDI Map Select.”
3. Press PARAMETER [ ] until “MIDI Program Map”
appears in the display.
fig.10-26
4. Press PARAMETER [ ] [ ] to move the cursor,
and rotate the PATCH/VALUE dial to set the received
Program number and the corresponding patch number.
5. Repeat Step 4 as needed, setting patch numbers to their
corresponding Program numbers, until the Program
Change Map is completed.
6. Press [EXIT] to return to the Play screen.
Program Number Bank/Patch Number
1 U1-1
2 U1-2
3 U1-3
4 U1-4
5 U2-1
: :
: :
: :
39 U0-3
40 U0-4
41 u1-1
42 u1-2
: :
: :
: :
79 u0-3
80 u0-4
81 P1-1
82 P1-2
: :
: :
: :
119 P0-3
120 P0-4
121 P0-4
122 P0-4
: :
128 P0-4
1,4
2
3
1
6
Program Number
Patch Number
