12
Exporting to a WAV file
Here’s how the IN–OUT range of tracks 1 and 2 from
song 001 can be exported to a SCSI-connected DOS for-
mat external drive “A:DOS” as a stereo WAV file
named “Sound001.wav.”
1 Select song 001.
2 Assign the IN and OUT time locations.
(→D16 p.70)
3 Select Copy.
In the [TRACK] “EditTrk” tab page, set “EditType”
to “CopyTrack.”
4 Select the copy source track number.
Set “SourceTrack” to tracks “1-2.”
5 Select the clipboard as the copy destination track
number.
Set “DestTrack” to “Clip.”
6 Execute the copy.
Press the “Exec.” button, and reply to the “Are You
Sure?” message. When the copy is completed, the
display will indicate “Completed.” Press the “OK”
button.
7 Select Export.
Select the [TRACK] “Export” tab page.
8 Select the export destination drive.
Press the “DriveList” button to access the dialog
box. Select a DOS format drive. For this example,
select drive “A” and press the “OK” button to
return to the [TRACK] “Import” tab page.
9 Assign a name to the WAV file.
Press the “Rename” button to access the dialog
box, and modify the name. You can input a name of
up to eight characters.
A filename extension of .wav will be input
automatically.
0 Input date information for the WAV file.
Press the “Date” button to access the dialog box,
and input the year, month, day, hour, minute, and
second.
A Execute the export operation.
Press the “Exec.” button, and reply to the “Are You
Sure?” message. When the data has been exported,
the display will indicate “Completed.” Press the
“OK” button.
If an identically-named WAV file already
exists, the export operation cannot be exe-
cuted.
An “Erase” button has been added to the “CDR/RW”
tab page.
P4 CDR/RW: Creating and playing
a CD-R/RW
Refer to the D16 Owner’s Manual for details on 2–6.
1. CD-R/RW Information .............................................
[Trk01...99, BlankDisc, NoAudioTracks, NoDrive]
This displays the song that will be played from the CD-
R/RW disc.
Trk01...99: The song number within the CD-R/RW disc.
BlankDisc: Nothing has been written to the inserted
CD-R/RW disc.
NoAudioTracks: Either a CD-R/RW disc has not been
inserted, or no playable audio tracks were found on the
disc.
NoDrive: No drive is connected.
7. Erase ......................................................................
This erases the data that was written on the CD-RW.
This cannot be executed for a CD-R.
Be aware that erased data cannot be recovered.
The “ReadDel” tab page has been changed.
P1 ReadDel: Scene playback on/
off and editing
5. SONG
p.62
8. SCENE
p.65–
1
6
5
4
2
3
7
1
8
10
6
4 5 3
2
7
9
