Chapter 9 Connecting External Devices
Chapter 9
■ Sending Recorded
Performance Data to a MIDI
Device (Composer MIDI Out)
When Composer Out is active, you can send performance
data recorded with the KF-7 to a connected MIDI device or
computer.
When you turn on the power, this is set to “OFF” (data is not
sent).
1. Press the [Menu] button.
2. Touch <Composer MIDI Out>.
fig.09-04.eps
3. Touch to set ON or OFF.
4. Touch <Exit> to return to the Menu screen.
Connecting to Audio
Equipment
When you connect the KF-7 to audio equipment, you can
play the sounds from the KF-7 through the speakers on the
audio equipment or record your performances on a tape
recorder or other recording device.
When connecting, please use audio cables (sold separately)
with standard phone plugs.
■ Connectors
fig.09-
Output Jacks
You can connect audio equipment using audio cables (sold
separately) and play the sounds from the KF-7 through the
speakers on the connected equipment, or record your
performances on a tape recorder or other recording device.
If the input of the connected device is monaural, you must
use the L (Mono) jack.
Input Jacks
You can connect another sound source, such as audio
equipment or an electronic instrument, using audio cables
(sold separately). Play the sounds from the connected device
through the speakers on the KF-7.
If the input of the connected device is monaural, you must
use the L (Mono) jack.
■ Making the Connections
* To prevent malfunction and/or damage to speakers or other
devices, always turn down the volume, and turn off the power
on all devices before making any connections.
Playing Sounds from the KF-7 Through the
Speakers on Audio Equipment or Recording Your
Performances on a Recording Device
fig.09-
1. Turn the volume all the way down on the KF-7 and on
the device you’re about to connect.
KF-7
Input R/L
(Line In, Aux In)
