85
Appendices
Appendices
42 Keysync Flanger
No. Parameter Setting Value Value Dec. Initial
3 FL PreDelay 0.0 - 100 ms 0 - 125 5
4 FL Rate 0.05 - 10.00 Hz, note*2 1 - 222 10
5 FL Depth 0 - 127 0 - 127 50
6 FL Feedback -98 - +98% 0 - 98 89
9 FL Phase 0 - 180 degree 0 - 90 90
1 Filter Type OFF, LPF, HPF 0 - 2 0
2 Filter Cutoff 200 - 8000 Hz (*1) 0 - 16 7
7
StepRate Switch
OFF, ON 0 - 1 0
8 Step Rate 0.1 - 20.0 Hz, note*2 1 - 222 200
10 Keysync Switch OFF, ON 0 - 1 1
11 Keysync Thres 0 - 127 0 - 127 60
12 Keysync Phase 0 - 360 degree 0 - 180 0
13 EQ Low Gain -15 - +15 dB 0 - 30 15
14 EQ High Gain -15 - +15 dB 0 - 30 15
15 Balance D100:0W - D0:100W 0 - 100 50
16 Output Level 0 - 127 0 - 127 127
(*1) 200, 250, 315, 400, 500, 630, 800, 1000, 1250, 1600, 2000,
2500, 3150, 4000, 5000, 6300, 8000 Hz
43:Formant Filter
No. Parameter Setting Value Value Dec. Initial
1 OD Switch OFF, ON 0 - 1 1
2 OD Drive 0 - 127 0 - 127 127
3 Filter Vowel 1 a, e, i, o, u 0 - 4 0
4 Filter Vowel 2 a, e, i, o, u 0 - 4 1
5 Filter Rate 0.05 - 10.00 Hz, note*2 1 - 222 20
6 Filter Depth 0 - 127 0 - 127 127
9 Filter Manual 0 - 100 0 - 100 50
7 Keysync Switch OFF, ON 0 - 1 1
8 Keysync Thres 0 - 127 0 - 127 60
10 EQ Low Gain -15 - +15 dB 0 - 30 15
11 EQ High Gain -15 - +15 dB 0 - 30 15
13 Output Level 0 - 127 0 - 127 127
12 Output Pan L64 - 63R 0 - 127 64
44:Ring Modulator
No. Parameter Setting Value Value Dec. Initial
1 RM Freq 0 - 127 0 - 127 60
2
RM MOD Source
OFF, SOURCE,
A, B, C, D 0 - 5 1
3
RM MOD Monitor
OFF, ON 0 - 1 1
4 RM Sens 0 - 127 0 - 127 0
5 RM Polarity UP, DOWN 0 - 1 0
6 EQ Low Gain -15 - +15 dB 0 - 30 15
7 EQ High Gain -15 - +15 dB 0 - 30 15
8 Balance D100:0W - D0:100W 0 - 100 50
9 Output Level 0 - 127 0 - 127 127
45:Multi Tap Delay
No. Parameter Setting Value Value Dec. Initial
1 DLY Time1 0 - 1800 ms, note*2 0 - 1822 1816
2 DLY Time2 0 - 1800 ms, note*2 0 - 1822 1815
3 DLY Time3 0 - 1800 ms, note*2 0 - 1822 1813
4 DLY Time4 0 - 1800 ms, note*2 0 - 1822 1810
13 DLY Feedback -98 - +98% 0 - 98 59
14 DLY HFDamp 200 - 8000 Hz,
BYPASS (*1) 0 - 17 17
9 DLY Level1 0 - 127 0 - 127 127
10 DLY Level2 0 - 127 0 - 127 127
11 DLY Level3 0 - 127 0 - 127 127
12 DLY Level4 0 - 127 0 - 127 127
5
DLY Output Pan1
L64 - 63R 0 - 127 0
6
DLY Output Pan2
L64 - 63R 0 - 127 32
7
DLY Output Pan3
L64 - 63R 0 - 127 96
8
DLY Output Pan4
L64 - 63R 0 - 127 127
15 EQ Low Gain -15 - +15 dB 0 - 30 15
16 EQ High Gain -15 - +15 dB 0 - 30 15
17 Balance D100:0W - D0:100W 0 - 100 50
18 Output Level 0 - 127 0 - 127 127
(*1) 200, 250, 315, 400, 500, 630, 800, 1000, 1250, 1600, 2000,
2500, 3150, 4000, 5000, 6300, 8000 Hz, BYPASS
46:Reverse Delay
No. Parameter Setting Value Value Dec. Initial
2 DLY Time1 0 - 900 ms, note*2 0 - 922 913
3 DLY Time2 0 - 900 ms, note*2 0 - 922 910
4 DLY Time3 0 - 900 ms, note*2 0 - 922 913
5 DLY Time4 0 - 900 ms, note*2 0 - 922 913
6 DLY Feedback1 -98 - +98% 0 - 98 49
7 DLY Feedback4 -98 - +98% 0 - 98 54
8 DLY HF Damp1 200 - 8000 Hz,
BYPASS (*1) 0 - 17 17
9 DLY HF Damp4 200 - 8000 Hz,
BYPASS (*1)0 - 17 17
13 DLY Level1 0 - 127 0 - 127 127
14 DLY Level2 0 - 127 0 - 127 64
15 DLY Level3 0 - 127 0 - 127 64
10 DLY Pan 1 L64 - 63R 0 - 127 64
11 DLY Pan 2 L64 - 63R 0 - 127 0
12 DLY Pan 3 L64 - 63R 0 - 127 127
1 Threshold 0 - 127 0 - 127 30
17 EQ Low Gain -15 - +15 dB 0 - 30 15
18 EQ High Gain -15 - +15 dB 0 - 30 15
16 Balance D100:0W - D0:100W 0 - 100 50
19 Output Level 0 - 127 0 - 127 127
(*1) 200, 250, 315, 400, 500, 630, 800, 1000, 1250, 1600, 2000,
2500, 3150, 4000, 5000, 6300, 8000 Hz, BYPASS
47:Shuffle Delay
No. Parameter Setting Value Value Dec. Initial
1 DLY Time 0 - 1800 ms, note*2 0 - 1822 1813
2
DLY ShuffleRate
0 - 100% 0 - 100 67
7
DLY Acceleration
0 - 15 0 - 15 10
6 DLY Feedback -98 - +98% 0 - 98 59
8 DLY HF Damp 200 - 8000 Hz,
BYPASS (*1) 0 - 17 17
3 Pan A L64 - 63R 0 - 127 0
4 Pan B L64 - 63R 0 - 127 127
5 Balance A100:0B - A0:100B 0 - 100 50
9 EQ Low Gain -15 - +15 dB 0 - 30 15
10 EQ High Gain -15 - +15 dB 0 - 30 15
11 Lev Balance D100:0E - D0:100W 0 - 100 50
12 Output Level 0 - 127 0 - 127 127
(*1) 200, 250, 315, 400, 500, 630, 800, 1000, 1250, 1600, 2000,
2500, 3150, 4000, 5000, 6300, 8000 Hz, BYPASS
