14
Before You Start Playing
Setting Up the Music Stand
fig.01-03
1. Attach the music stand by inserting it into the
two holes.
Connecting the AC Adaptor
1. First, make sure that the [Power On] switch at
the panel’s left side is OFF (not pushed in).
2. Connect the supplied AC adaptor and power
cord.
3. Connect the AC adaptor to the DC In jack on the
rear panel.
4. Loop the AC adaptor cord around the cord hook
to fasten it in place.
* To prevent the inadvertent disruption of power to your unit
(should the plug be pulled out accidentally), to avoid applying
undue stress to the DC In connector, anchor the power cord
using the cord hook, as shown in the diagram. Even if the cord is
fastened, strong tension applied to the cord may cause it to be
damaged or broken. Be careful not to pull the cord accidentally,
or to apply strong pressure to it.
5. Plug the power cord into a power outlet.
fig.01-05
* Only use the power cord and AC adaptor supplied with this
instrument.
* Whenever you do not intend to use the instrument for extended
periods of time, pull out the power cord from the AC outlet.
