Specifications
Mechanical Characteristics
Tape: Compact Cassette (C-30 to 90), High-Bias (CrO2)
Track Format: 4-track/4-channel
Head Configuration: 4-channel record/play (permalloy) x 1
4-channel erase (ferrite) x 1
Motor: DC servo motor x 1
Tape Speed: Switchable two speeds: 9.5 cm/sec. (3-3/4 ips) and
4.8 cm/sec. (1-7/8 ips), ± 1%
Pitch Control: ± 12 % (approx.)
Wow and Flutter: 0.06% WRMS at 4.8 cm/sec.,
0.05% WRMS at 9.5 cm/sec.
Fast Winding Time: 120 sec. (approx.) with C-60
Dimensions (W × H × D) 419 x 115 x 357 mm (16-1/2" x 4-1/2" x 14-1/16")
Weight: 4.9 kg (10.8 lbs.)
Mixer Section
MIC/LINE INPUT, Ch.1-4
(XLR type connector x 4)
Input Impedance: 3.6k ohms
Nominal Input Level: –60 dBV (1mV) (MIC position)
–20 dBV (0.1 V) (LINE position)
Maximum Input Level: +3 dBV (1.4 V) at Trim Min.
MIC/LINE INPUT, Ch.1-6
(1/4" phone jack x 6)
Input Impedance: 5.6k ohms
Nominal Input Level: –50 dBV (3mV) (MIC position)
–10 dBV (0.3 V) (LINE position)
Maximum Input Level: +10 dBV (3 V) at Trim Min.
STEREO INPUT, Ch.7-8
(1/4" phone jack x 2)
Input Impedance: 10k ohms
Nominal Input Level: –10 dBV (0.3 V)
Maximum Input Level: +10 dBV (3 V)
SUB INPUT (RCA jack x 2)
Input Impedance: 10k ohms
Nominal Input Level: –10 dBV (0.3 V)
Maximum Input Level: +10 dBV (3 V)
LINE OUTPUT (RCA jack x 2)
Output Impedance: 100 ohms
Nominal Output Level: –10 dBV (0.3 V)
Minimum Load Impedance: 2k ohms
EFFECT 1 SEND (1/4" phone jack)
Output Impedance: 100 ohms
Nominal Output Level: –10 dBV (0.3 V)
Minimum Load Impedance: 2k ohms
Electrical Characteristics
