CLP-F01 Selecting & Playing Voices
ENGLISH
26
Touch Sensitivity – [TOUCH]
You can select four different types of keyboard touch sensitivity — HARD, MEDIUM, SOFT or FIXED
— to match different playing styles and preferences.
HARD: Requires that the keys be played quite hard to produce maximum loud-
ness.
MEDIUM: Produces a fairly “standard” keyboard response.
SOFT: Allows maximum loudness to be produced with relatively light key pres-
sure.
FIXED: All notes are produced at the same volume no matter how hard the key-
board is played.
You can adjust the volume.
To select a touch sensitivity type press the
[TOUCH] button a few times until the indica-
tor corresponding to the desired type lights (the indicators light in sequence each time
the
[TOUCH] button is pressed). No indicator is lit when “FIXED” is selected.
Changing the volume when FIXED is selected
When you select FIXED, you can set the volume for notes
played in FIXED mode by using the
[–/NO] and [+/YES] but-
tons while you hold the [TOUCH] button. The current vol-
ume level appears on the display. The volume range is from 1
through 127. The default setting is 64.
TIP
This setting does not change
the weight of the keyboard.
TIP
Normal setting = MEDIUM
TIP
The touch sensitivity type will
become the common setting for
all voices. However, the touch
sensitivity settings may have lit-
tle or no effect with certain
voices that are not normally
responsive to keyboard dynam-
ics. (Refer to the “Preset Voice
List” on page 62.)
MASTER VOLUME
BRILLIANCE
MELLOW BRIGHT
MIN MAX
DEMO METRONOME
START/STOP
TEMPO
/
FUNCTION
TEMPO
FUNCTION
TEMPO/OTHER VALUE
-
NO YES
+
PRESET
USER 1
USER 2
TRACK
1
TRACK
2
START/STOP
REC
USER 3
SONG
GRAND
PIANO 1
CHURCH
ORGAN
STRINGS
E.PIANO
2
E.PIANO
1
VIBRA-
PHONE
HARPSI-
CHORD
CHOIR E.BASS SPLIT
VARIATION
GRAND
PIANO 2
GRAND
PIANO 3
JAZZ
ORGAN
WOOD
BASS
VOICE
GUITAR/
CLAVI.
ROOM
HALL 1
HALL 2
STAGE
CHORUS
PHASER
TREMOLO
DELAY
HARD
MEDIUM
SOFT
ON
REVERB EFFECT TOUCH TRANSPOSE
[TOUCH]
[–/NO] [+/YES]
Procedure
TIP
1: minimum volume
127: maximum volume
TIP
The touch volume set in FIXED
mode will become the common
setting for all voices.
TIP
Releasing the [TOUCH] button
changes the touch type.
If you are changing the volume
by holding the [TOUCH] button,
pressing the [TOUCH] button
will not change the touch sensi-
tivity type. (FIXED mode will
remain selected.)
volume range
