CLP-F01 Detailed Settings – [FUNCTION]
ENGLISH
47
You can change the volume of the metronome
sound.
Use this function to adjust the metronome vol-
ume.
1. Engage Function mode and select .
2. Use the [–/NO] and [+/YES] buttons to set the
metronome volume as required.
Setting range: 1 – 20
Normal setting: 10
This function sets the volume at which a “can-
celed” part is played during preset song play-
back. Adjust the part volume to a comfortable
level and use the “canceled” part as a guide
with which to play along.
1. Engage Function mode and select .
2. Use the [–/NO] and [+/YES] buttons to set the
volume as required.
Setting range: 0 – 20
Normal setting: 5
You can make detailed adjustments to MIDI
settings.
For more information about MIDI, see the
“About MIDI” section (page 51).
1. Engage Function mode and select .
2. Press the [+/YES] button to engage the MIDI
function’s sub-mode, then use the [TEMPO/
FUNCTION# ▼ ▲] buttons to select the
desired sub-mode.
Press the [–/NO] or [+/YES] button to set a
selected parameter.
Sub-mode
F8.1: MIDI Transmit Channel Selection
In any MIDI control setup, the MIDI channels of the
transmitting and receiving equipment must be matched
for proper data transfer.
This parameter enables you to specify the channel on
which the Clavinova transmits MIDI data.
Setting range: 1 – 16, OFF (not transmitted)
Normal setting: 1
F6. Metronome Volume
TIP
SHORTCUT:
You can jump directly to the metronome functions by
pressing the [TEMPO/FUNCTION#] button while holding the
METRONOME [START/STOP] button.
To exit Function mode, you still need to press the [TEMPO/
FUNCTION#] button so that the TEMPO indicator lights up.
F7.
Preset Song Part Cancel Volume
F8. MIDI Functions
TIP
The HOST SELECT switch on the bottom surface must be
set to “MIDI” to enable the MIDI connectors. When you use
the TO HOST connector, set the HOST SELECT switch to
the appropriate position for the type of computer you are
using (pages 51–57). In this situation, all MIDI settings
described below will affect the MIDI signal in and out of the
TO HOST connector.
NOTE
In Dual mode, Voice 1 data is transmitted on its specified
channel. In Split mode, right voice data is transmitted on its
specified channel. In Dual mode, Voice 2 data is transmitted
on the next greater channel number relative to the specified
channel. In Split mode, left voice data is transmitted on the
next greater channel number relative to the specified chan-
nel. In either mode, no data is transmitted if the transmit
channel is set to “OFF”.
NOTE
Demo/preset song data and recorder playback data are not
transmitted via MIDI.
