CLP-F01 Detailed Settings – [FUNCTION]
ENGLISH
42
About Each Function
You can fine tune the pitch of the entire instru-
ment. This function is useful when you play
the Clavinova along with other instruments or
CD music.
1. Engage Function mode and select .
2. Use the [–/NO] and [+/YES] buttons to lower
or raise the pitch of the A3 key in approxi-
mately 0.2 Hz increments.
..... .....
Te nths of a hertz are indicated on the LED display by
the appearance and position of one or two dots, as in
the following example:
•Refer to “Panel Controls and Terminals” on page 16
for information on the key and key name assignment.
(During the procedure described above, the display indi-
cates a value in Hz < … >. After the proce-
dure, the display returns to the previous indication.)
(During the procedure described above, the display indi-
cates a value in Hz < … >. After the proce-
dure, the display returns to the previous indication.)
F1. Fine Tuning of the Pitch
Display Value
440.0
Setting range:
440.2
427.0–453.0 (Hz)
440.4
Normal setting:
440.6
440.0 (Hz)
440.8
TERMINOLOGY
Hz (Hertz):
This unit of measurement refers to the frequency of a sound
and represents the number of times a sound wave vibrates in
a second.
TIP
You can also use the keyboard to set the pitch (in any
mode other than Function mode).
To tune up (in about 0.2Hz steps): Hold the A-1 and B-1
keys (two white keys at the left end) simultaneously and
press any key between C3 and B3.
To tune down (in about 0.2Hz steps): Hold the A-1 and A
-
1 keys (a white and a black key at the left end) simulta-
neously and press any key between C3 and B3.
To restore standard pitch: Hold the A-1, A
-1 and B-1 (two
white keys and one black key at the left end) simultaneously
and press any key between C3 and B3.
TIP
You can also tune in about 1Hz steps (in any mode other
than Function mode).
To tune down or up, respectively, in approximately 1 Hz
increments: Hold the A-1 and A
-1 keys (a white and a black
key at the left end) or A-1 and B-1 keys (two white keys at the
left end) simultaneously and press the [–/NO] or [+/YES] but-
ton.
To restore standard pitch: Hold the A-1 and A
-1 keys (a
white and a black key at the left end) or A-1 and B-1 keys
(two white keys at the left end) simultaneously and press the
[–/NO] [+/YES] buttons simultaneously.
