CLP-F01 Selecting & Playing Voices
ENGLISH
28
Combining Two Voices (Dual mode)
You can play two voices simultaneously across the entire range of the keyboard. In this way, you
can simulate a melody duet or combine two similar voices to create a thicker sound.
1 Engage Dual mode.
Press two voice buttons at the same time (or press one voice button while hold-
ing another). The voice indicators of both selected voices will light when Dual
mode is active.
•According to the voice numbering
priority shown in the diagram on
the right, the lower value voice
number will be designated as Voice
1 (the other voice will be desig-
nated as Voice 2).
The CLP-F01 Function mode provides access to a number of other Dual mode
functions, such as volume balance setting or octave setting (page 44). (If you do
not set Dual mode functions, the appropriate setting will be set in each voice by
default.)
2 Exit Dual mode and return to normal play mode.
To return to the normal single-voice play mode, press any single voice button.
MASTER VOLUME
BRILLIANCE
MELLOW BRIGHT
MIN MAX
DEMO METRONOME
START/STOP
TEMPO
/
FUNCTION
TEMPO
FUNCTION
TEMPO/OTHER VALUE
-
NO YES
+
PRESET
USER 1
USER 2
TRACK
1
TRACK
2
START/STOP
REC
USER 3
SONG
GRAND
PIANO 1
CHURCH
ORGAN
STRINGS
E.PIANO
2
E.PIANO
1
VIBRA-
PHONE
HARPSI-
CHORD
CHOIR E.BASS SPLIT
VARIATION
GRAND
PIANO 2
GRAND
PIANO 3
JAZZ
ORGAN
WOOD
BASS
VOICE
GUITAR/
CLAVI.
ROOM
HALL 1
HALL 2
STAGE
CHORUS
PHASER
TREMOLO
DELAY
HARD
MEDIUM
SOFT
ON
REVERB EFFECT TOUCH TRANSPOSE
12
Procedure
NOTE
Dual and Split (page 29) modes
cannot be engaged at the same
time.
TIP
[VARIATION] in Dual Mode
The [VARIATION] button’s indi-
cator will light if the variation is
engaged for either or both of the
Dual mode voices. While Dual
mode is engaged, the [VARIA-
TION] button can be used to
turn the variation for both voices
on or off.
To turn the variation on or off for
only one of the voices, hold the
voice button for the other voice
and press the button of the voice
for which you want to change
the variation.
TIP
[REVERB] in Dual Mode
The reverb type assigned to
Voice 1 will take priority over the
other. (If the reverb is set to OFF,
Voice 2 reverb type will be in
effect.) Reverb depth setting via
the panel controls (i.e., pressing
the [–/NO] or [+/YES] buttons
while holding the [REVERB] but-
ton — see page 24) will be
applied only to Voice 1.
TIP
[EFFECT] in Dual Mode
Depending on the conditions,
one effect type may take priority
over the other. Depth will be
decided according to the depth
default value of the voice combi-
nation. However, using function
F3 (page 44) you can adjust the
depth value for each voice to
your liking.
Effect depth setting via the panel
controls (i.e., pressing the [–/
NO] or [+/YES] buttons while
holding the [EFFECT] button —
see page 25) will be applied only
to Voice 1.
GRAND
PIANO 1
CHURCH
ORGAN
STRINGS
E.PIANO
2
E.PIANO
1
VIBRA-
PHONE
HARPSI-
CHORD
CHOIR E.BASS
GRAND
PIANO 2
GRAND
PIANO 3
JAZZ
ORGAN
WOOD
BASS
VOICE
GUITAR/
CLAVI.
12
12 13 14
34567
891011
Voice numbering priority
