CLP-F01 Detailed Settings – [FUNCTION]
ENGLISH
48
F8.2: MIDI Receive Channel Selection
In any MIDI control setup, the MIDI channels of the
transmitting and receiving equipment must be matched
for proper data transfer. This parameter enables you to
specify the channel on which the Clavinova receives
MIDI data.
Setting range: ALL, 1&2, 1 – 16
Normal setting: ALL
F8.3: Local Control ON/OFF
“Local Control” refers to the fact that, normally, the
CLP-F01 keyboard controls its internal tone generator,
allowing the internal voices to be played directly from the
keyboard. This situation is “Local Control On,” since the
internal tone generator is controlled locally by its own
keyboard.
Local control can be turned OFF, however, so that the
CLP-F01 keyboard does not play the internal voices, but
the appropriate MIDI information is still transmitted via
the MIDI OUT connector when notes are played on the
keyboard. At the same time, the internal tone generator
responds to MIDI information received via the MIDI IN
connector.
Setting range: ON/OFF
Normal setting: ON
F8.4: Program Change ON/OFF
Normally the CLP-F01 will respond to MIDI program
change numbers received from an external keyboard or
other MIDI device, causing the correspondingly-num-
bered voice to be selected on the corresponding channel
(the keyboard voice does not change). The CLP-F01 will
normally also send a MIDI program change number
whenever one of its voices is selected, causing the corre-
spondingly-numbered voice or program to be selected
on the external MIDI device if the device is set up to
receive and respond to MIDI program change numbers.
This function makes it possible to cancel program
change number reception and transmission so that
voices can be selected on the CLP-F01 without affecting
the external MIDI device.
Setting range: ON/OFF
Normal setting: ON
F8.5: Control Change ON/OFF
Normally the CLP-F01 will respond to MIDI control
change data received from an external MIDI device or
keyboard, causing the voice on the corresponding chan-
nel to be affected by pedal and other “control” settings
received from the controlling device (the keyboard voice
is not affected).
The CLP-F01 also transmits MIDI control change infor-
mation when the pedal or other appropriate controls are
operated.
This function makes it possible to cancel control change
data reception and transmission so that, for example, the
CLP-F01’s pedal and other controls can be operated
without affecting an external MIDI device.
Setting range: ON/OFF
Normal setting: ON
TIP
ALL:
A “Multi-timbre” Receive mode is available. It allows simulta-
neous reception of different parts on all 16 MIDI channels,
enabling the Clavinova to play multi-channel song data
received from a music computer or sequencer.
1&2:
A “1&2” Receive mode is available. It allows simultaneous
reception on channels 1 and 2 only, enabling the Clavinova to
play 1 and 2 channel song data received from a music com-
puter or sequencer.
TIP
Program change and other like channel messages received
will not affect the CLP-F01’s panel settings or the notes you
play on the keyboard.
NOTE
No MIDI reception occurs when Demo/Preset Song mode is
engaged.
TIP
For information on program change numbers for each of the
CLP-F01’s voices, refer to page 69 in the MIDI Data Format
section.
TIP
For information on control changes that can be used with the
CLP-F01, refer to the MIDI Data Format on page 69.
