CLP-F01 Recording Your Performance
ENGLISH
32
Recording Your Performance
The ability to record and play back what you’ve played on the CLP-F01
keyboard can be an effective practice aid. You can, for example, record
just the left-hand part, and then practice the right-hand part while
playing back the recorded left-hand part. Or, since you can record up
to two tracks separately, you could record the left- and right-hand parts
separately, or record both parts of a duet and hear how they sound
when played back. The CLP-F01’s two-track Song Recorder allows the
recording of up to three User Songs.
Recording to [TRACK 1]
CAUTION
Notes on recording
All user song recorder data will be retained in memory for about one week after the
power is turned off. If you want to keep your recorded data for longer periods of time,
turn the power on for a few minutes at least once a week.
It is also possible to store the data to an external MIDI storage device such as the
Yamaha MIDI Data Filer MDF3 by using the Bulk Data Dump function described on
page 49.
1 Select a song for recording.
Press the [USER 1/2/3] button to select a song for recording.
The indicator of the selected song will light. (No song is selected if none of the
indicators are lit.)
2 Make all the initial settings.
Before you begin to record, select the voice you want to record (or voices if you
will be using Dual or Split mode). Make any other desired settings (tempo,
reverb, etc.) as well. You might also want to set the volume.
You can also adjust the playback volume using [MASTER VOLUME].
TIP
You can record your perfor-
mance (audio data) to a cas-
sette tape recorder or other
recording device via the AUX
OUT connector (page 52).
TERMINOLOGY
Recording vs. Saving:
The format of performance data
recorded on a cassette tape dif-
fers from that of data recorded
on the Clavinova. A cassette
tape records audio signals. The
Clavinova “saves” information
regarding note timing, voices,
and a tempo value, but not
audio signals. When you play
back recorded songs, the Clavi-
nova produces sound based on
the saved information. There-
fore, recording on the Clavinova
may be more accurately called
“saving information.” However,
this book often uses the word
“recording” because it seems to
make more sense.
MASTER VOLUME
BRILLIANCE
MELLOW BRIGHT
MIN MAX
DEMO METRONOME
START/STOP
TEMPO
/
FUNCTION
TEMPO
FUNCTION
TEMPO/OTHER VALUE
-
NO YES
+
PRESET
USER 1
USER 2
TRACK
1
TRACK
2
START/STOP
REC
USER 3
SONG
GRAND
PIANO 1
CHURCH
ORGAN
STRINGS
E.PIANO
2
E.PIANO
1
VIBRA-
PHONE
HARPSI-
CHORD
CHOIR E.BASS SPLIT
VARIATION
GRAND
PIANO 2
GRAND
PIANO 3
JAZZ
ORGAN
WOOD
BASS
VOICE
GUITAR/
CLAVI.
ROOM
HALL 1
HALL 2
STAGE
CHORUS
PHASER
TREMOLO
DELAY
HARD
MEDIUM
SOFT
ON
REVERB EFFECT TOUCH TRANSPOSE
2
541673
NOTE
When the unit is in Demo Song
mode, the [USER 1/2/3] button
cannot be used to select a song.
NOTE
When the unit is in Demo Song
or Preset Song mode, Record
mode cannot be engaged.
NOTE
To avoid erasing data from
the track:
If the track contains data, the
track indicator lights up green
when you press the [USER 1/2/
3] button. Note that recording
new data on this track will erase
the existing data.
Procedure
