CLP-F01 Detailed Settings – [FUNCTION]
ENGLISH
49
F8.6: MIDI Transmit Transpose
This function allows the MIDI note data transmitted by
the CLP-F01 to be transposed up or down in semitone
increments by up to plus or minus 12 semitones. The
pitch of the CLP-F01 itself is not affected.
Setting range: -12 – 0 – 12 (in semitones)
Normal setting: 0
F8.7: Panel/Status Transmit
This function causes all the current CLP-F01 panel set-
tings (selected voice, etc.) to be transmitted via the MIDI
OUT terminal. This is particularly useful if you will be
recording performances to a MIDI sequence recorder,
such as the Yamaha MIDI Data Filer MDF3, which will
be used to control the CLP-F01 on playback. By trans-
mitting the CLP-F01 panel settings and recording them
on the MIDI sequence recorder prior to the actual per-
formance data, the CLP-F01 will be automatically
restored to the same settings when the performance is
played back.
Procedure
1. Set up the panel controls as desired.
2. Connect the Clavinova to a sequencer via MIDI, and
set up the sequencer so it can receive the setup data.
3. Engage Function mode and select .
4. Press the
[+/YES] button to transmit the panel/status
data.
will appear on the LED display when the data has
been successfully transmitted.
F8.8: Bulk Data Dump
You can save current song data on the Clavinova as MIDI
bulk data by transferring it to a connected MIDI data
filer (such as an MDF3) or a sequencer. To play back the
saved song data, send the bulk data back from the storage
device to the Clavinova and follow the usual playback
procedure.
Procedure
1. Record your performance on the Clavinova.
2. Connect the Clavinova to MDF3, a MIDI data filer via
MIDI, and set up the MDF3 so it will receive bulk
data.
3. Engage Function mode and select .
4. Press the
[+/YES] button to begin bulk transmission.
will appear on the LED display when the data has
been successfully transmitted.
TERMINOLOGY
Setup Data:
Data that contains a set of panel settings for the Clavinova.
TIP
See page 70 for a list of the “Panel Data Contents” transmit-
ted by this function.
TIP
Receiving the transmitted data:
1. Connect the Clavinova via MIDI to the device to which the
setup data was transmitted previously.
2. Start sending the setup data from the device.
The Clavinova automatically receives the setup data, which
will be reflected in the panel settings.
(For the data to be accepted, the Clavinova that receives the
setup data should be the same model as the one that trans-
mitted the setup data to the sequencer.)
TIP
For more information on transmitting and receiving setup
data via MIDI, refer to the owner’s manual for the connected
MIDI device.
TERMINOLOGY
bulk data:
A complete set or extended sequence of data.
NOTE
No MIDI note/panel data transmission or data reception
occurs during a bulk data dump transmit operation.
TIP
Receiving (returning) the transmitted data:
1. Connect the CLP-F01 via MIDI to the device to which the
data was previously transmitted.
2. Start sending the data from the device.
The CLP-F01 automatically receives the data from the unit.
(At this time, any data previously stored in the Clavinova will
be erased.)
Then, follow the usual playback procedure.
(For the data to be accepted, the Clavinova that receives the
data should be the same model as the one from which the
data was once transmitted to the MIDI data filer.)
NOTE
The reload operation cannot be executed when Demo/Preset
Song mode or the user song recorder is in operation, or
when Function mode is engaged.
TIP
For more information on transmitting and receiving bulk data
via MIDI, refer to the owner’s manual for the connected MIDI
device.
