98 Advanced recording techniques
—Owner’s Manual
Controlling the MD4S by MMC
MMC (MIDI Machine Control) is a type of MIDI message that allows the transport of an
audio/video recorder etc. to be controlled by an external MIDI device. Since the MD4S is able
to receive MMC, an MMC-compatible MIDI sequencer or other device can control the trans-
port of the MD4S. In this case, the device that transmits MMC data will be the MMC Master,
and the device that receives MMC data will be the MMC Slave.
The MD4S supports the following MMC messages.
■ Switching MMC reception on/off
You can specify whether or not the MD4S will receive MMC.
1. Press the UTILITY button, rotate the DATA dial to make the display read
“MMC Receive,” and press the ENTER button.
The display will indicate the current MMC reception setting. With the factory settings this is
off, and the display will indicate “MMC Rx OFF.”
2. Rotate the DATA dial to switch the setting “ON” or “OFF.”
When this is “ON,” MMC can be received.
3. Press the ENTER button to confirm the setting.
Function MMC# MD4S operation
Stop Command 01
If this command is received during recording,
rehearsal, or playback etc., that operation will be
halted.
Playback Command 02, 03
When this command is received, playback will
begin. If this command is received during record-
ing or rehearsal, that operation will be halted.
Fast-forward Command 04
Skip to the next song. If this command is received
during recording or rehearsal, that operation will
be halted.
Rewind Command 05
Skip to the previous song. If this command is
received during recording or rehearsal, that opera-
tion will be halted.
Record Strobe Command 06
If this command is received when stopped, record-
ing will begin. If this command is received during
playback, punch-in will be performed. If received
while paused, this command will be ignored.
End Record Command 07 Record mode will be turned off.
Paus Command 09
Enter pause mode. If received during record or
rehearsal, stop.
MMC Reset Command 0D
Reset MMC data to the initial settings (the condi-
tion at power-on).
Write Command 40 Write data to the specified data field.
Locate Command 44 Locate to the specified time code location.
Record Mode Data field 4C Switch between REHE and REC.
Track Record Ready Data field 4F
Select the track to be recorded by “Record
Strobe.”
