set fdb 101
See Also
■ “clear vlan” on page 91
■ “set vlan name” on page 103
■ “set vlan port” on page 104
■ “set vlan tunnel-affinity” on page 105
set fdb Adds a permanent or static entry to the forwarding database.
Syntax — set fdb {perm | static}
mac-addr port port-list vlan vlan-id [tag tag-value]
■ perm — Adds a permanent entry. A permanent entry does not age out
and remains in the database even after a reboot, reset, or power cycle.
■ static — Adds a static entry. A static entry does not age out, but is
removed from the database after a reboot, reset, or power cycle.
■ mac-addr — Destination MAC address of the entry. Use colons to
separate the octets (for example, 00:11:22:aa:bb:cc).
■ port port-list — List of physical destination ports for which to add
the entry. A separate entry is added for each port you specify.
Port Member port of the VLAN. The port can be a physical port or a
virtual port.
■ Physical ports are 10/100 Ethernet or gigabit Ethernet ports on
the WX switch, and are listed by port number.
■ Virtual ports are tunnels to other WX switches in a mobility
domain, and are listed as follows: t:ip-addr, where ip-addr is the
system IP address of the WX switch at the other end of the
tunnel.
Note: This field can include MAP access ports and wired
authentication ports, because MSS dynamically adds these ports to a
VLAN when handling user traffic for the VLAN.
Tag Tag value assigned to the port.
Port State Link state of the port:
■ Down — The port is not connected.
■ Up — The port is connected.
Table 24 Output for display vlan config (continued)
Field Description
