Commander GP User Guide
Issue code: gpxu2
Getting Started 2-3
4. When connecting a motor to the Drive, observe
the following:
• Preferably the motor should be identical to
the motor that is to be used in the
application, but this is not essential.
• The motor shaft must not be attached to
any equipment, or exposed.
5. No motor thermistor connection is required at
this stage, but a thermistor will be required
later if the Drive is to be operated in any macro
configuration except Macros 1 and 5. When
Macro 1 or Macro 5 is enabled, the thermistor is
ignored by the Drive. (Instructions for
connecting a motor thermistor to the signal
connector are given for each macro
configuration in Chapter 3 Setting Up the Drive.)
Warning
After having made control
connections, carefully check
that terminal 30 is open-circuit
to ensure the Drive is in the
Stop state when the
AC supply
is first connected.
6. After re-fitting the terminal cover, connect the
Drive to the
AC supply.
