Commander GP User Guide
Issue code: gpxu2
Menu 0 Parameters D-1
D Menu 0 Parameters
D.1 Introduction
Key
Type of parameter
RO Read-only
RW Read–write
...selector Select from a number of settings
...select Select from two settings
...enable Make or allow a function to operate
...disable Stop or disallow a function from
operating
...indicator The value can only be read
Limitations of use
R The Drive must be reset for a new value to
take effect.
S The new parameter-value is saved when the
AC supply is disconnected from the Drive.
P Protected parameter; the parameter cannot
be used as the destination parameter for a
programmable input.
Range
Bi Variable parameter having bipolar value
range.
Uni Variable parameter having unipolar value
range.
Txt Variable parameter having text displayed. A
number is stated alongside the setting; this is
displayed on the system controller when the
Drive is accessed by serial communications
Bit Bit parameter
FLC Full-load current (maximum continuous
output current) (see Appendix C Data in the
Installation Guide)
Symbols
Default value
Range of values
[...] Indicates the value of the parameter
~ Indicates a range of values (in the case of bit
parameters, ~ indicates or)
Categories of the
fixed-function parameters
The parameters are arranged in the following
categories:
0.00 Configuration and saving
0.01 ~ 0.02 Frequency limits
0.03 ~ 0.06 Ramps
Frequency reference selection
Current limit
0.07 ~ 0.09 Voltage boost
0.10 Speed indication
0.31 Macro-number indication
0.32 ~ 0.34 Miscellaneous
0.35 Keypad-reference monitoring
0.36 ~ 0.38 Serial communications
Parameter displayed at power-up
0.39 ~ 0.41 Spinning motor
Autotune
PWM switching frequency
0.42 ~ 0.47 Motor parameters
0.48 Drive software build number
0.49 ~ 0.50 Security and software information
