Commander GP User Guide
Issue code: gpxu2
3-40 Setting Up the Drive
Reference selection
Frequency reference 1
(remote)
Frequency reference 2
(local)
LIMIT
FORWARD
RUN
(FORWARD)
RUN
REVERSE
The parameters are shown at their default settings.
The logic diagram is valid when all parameters are
at their default settings but may not be valid when
certain parameters are adjusted.
5
6
7
0.05
Reference
selector
29
LIMIT
REVERSE
2627 28
Minimum
frequency
clamp
0.01
0.02
0.21
Limit
forward
invert
Power up
parameter
display
setting
0.38
0.XX
0.XX
X X
X X
Key
Read-write (RW)
parameter
Read-only (RO)
parameter
Input terminals
Output terminals
Maximum
frequency
clamp
Limit
forward
indicator
0.14
Run
forward
indicator
0.15
0.17
0.16 0.22
Run
reverse
indicator
Limit
reverse
indicator
Limit
reverse
invert
Forward
frequency
reference
Frequency
reference
Direction control
Bi-directional
frequency
reference
Reverse
frequency
reference
RUN enabled
RUN disabled (at limit)
0 =
1 =
Figure 3–16 Programmable software for Macro 6
