Commander GP User Guide
Issue code: gpxu2
3-22 Setting Up the Drive
Reference selection
Frequency reference 1
(remote)
PRESET
SELECT
B
RUN
FORWARD
RUN
REVERSE
RESET
The parameters are shown at their default settings.
The logic diagram is valid when all parameters are
at their default settings but may not be valid when
certain parameters are adjusted.
0.24
5
6
0.25
Analog input 1
mode
selector
0.05
Reference
selector
29
PRESET
ENABLE
27 28
Minimum
frequency
Maximum
frequency
0.01
0.02
0.20
0.21
0.22
0.23
Skip
frequency 1
Skip band 1
Skip
frequency 2
Skip band 2
Skip
frequencies
Initial
parameter
displayed
0.38
25
24
PRESET
SELECT
A
30
EXTERNAL TRIP
Preset
reference 2
0.26
0.27
0.28
Preset
reference 3
Preset
reference 4
Preset
reference 1
26
0.XX
0.XX
X X
X X
Key
Read-write (RW)
parameter
Read-only (RO)
parameter
Input terminals
Output terminals
A
0
0
1
1
B
0
1
0
1
Preset
frequency
1
2
3
4
Figure 3–9 Programmable software for Macro 3
