72
Chapter 12. Using the SP-505 with other MIDI devices
Never turn off the power while the display indicates
“Keep Power On!”
The SP-505 transmits pad performance data as sets
consisting of “program change message + note
message.” If this performance data is overdubbed on an
external sequencer, some sequencers may automatically
rearrange the overdubbed data, making it impossible for
the performance data to be reproduced correctly.
Synchronizing the
performance of the SP-505
and an external MIDI device
In order for the performance to be synchronized with an
external MIDI device, you must decide which device (the SP-
505 or the external MIDI device) will control start/stop, and
which device will determine the BPM (Sync mode).
Connections for synchronized
performance
Use a MIDI cable to connect the MIDI OUT connector of the
master device to the MIDI IN connector of the SP-505.
fig.12-03
Sync mode settings
1. Press [SONG] or [PTN] to display the Play screen.
2. Press [SYSTEM] to display the System screen.
fig.10-01a
* It is not possible to display the System screen while a pattern
or song is playing.
3. Press [F1] (UTILITY).
4. Press [F2] (MIDI).
The MIDI Settings screen will appear.
5. Press CURSOR [↓] to select Sync Mode, and use the
VALUE dial to change the setting.
fig.12-04
* If the Sync Mode is set to MIDI, playback will not occur
unless MIDI Clock messages are received from an external
MIDI device.
6. Press [PTN] or [SONG] to return to the Play screen.
Never turn off the power while the display indicates
“Keep Power On!”
* At the factory settings, this is set to AUTO.
* It is not possible to change the MIDI settings while the
sequencer is playing.
Master
Slave (SP-505)
MIDI INMIDI OUT
Start/Stop BPM
INT Control from SP-505
only
Use SP-505’s internal
BPM
MIDI Control from SP-505/
Control from external
MIDI device
Use MIDI Clock
messages
REMOTE Control from SP-505/
Control from external
MIDI device
Use SP-505’s internal
BPM
AUTO Control from SP-505 Use SP-505’s internal
BPM
Control from external
MIDI device
Use MIDI Clock
messages
