System 5-B Digital Audio Mixing System Operation Manual Channels and Strips
106
The dynamics function consists of the following controls (see Figure 8-10).
Compressor
cGmu: gain makeup (dB)
cDpt: compressor depth limits the maximum gain reduction in the compressor
cRel: Compressor release time
cAtk: Compressor attack time
cThr: Compressor threshold (dB)
cRat: ratio (infinity:1 = hard limiter)
The lower switch next to the cRat knob switches the compressor in/out.
Expander/Gate
xDpt: expander depth limits the maximum gain reduction in the expander
xRel: Expander release time
xAtk: Expander attack time
xThr: Expander threshold (dB)
xRat: ratio (infinity:1 = gate)
The lower switch next to the xRat knob switches the expander in/out.
Sidechain
SC: sidechain source (channel, key, link)
The lower switch next to the SC knob activates sidechain listen mode for that channel.
