8.3.3 Equalizers and Filters
Each channel has a four-band, parametric equalizer and two filters. Press the EQ func-
tion switch to display the EQ controls on the knobset. Press the X key to display the
Filters page (Figure 8-11).
Figure 8-11 EQ and Filters knobsets
