System 5-B Digital Audio Mixing System Operation Manual Channels and Strips
116
Figure 8-16 Changing processor order
3. When that processor’s position is correct, press the fader Select/Punch key
(above the Wave key) to accept the new order.
The knob display changes only after pressing the Select/Punch key.
Press the switch next to the Channel On key to abort the selection.
8.4.3 Insert Point
Each channel can have an insert point with a send and return that can be patched with
PatchNet. The insert point can be anywhere among the six processors (Delay, Metering,
EQ, Filters, Dynamics, and Fader) and can be considered as another processor.
The insert point can be switched in/out using the Ins In key next to the Strip’s function
keys or from the third Input knobset page.
12
6
0
6
12
on
A
bort selection
A
ccept selection
Wave key
Fader scrolls
through
list
