CLP-295GP Owner’s Manual 91
Detailed Settings
Other settings [FUNCTION]
Select the volume level of the signal output from
the AUX OUT jacks. When “Fixed” is selected, the
level cannot be controlled by using the [MASTER
VOLUME] control. When “Variable” is selected,
the level can be controlled by using the [MASTER
VOLUME] control.
See the procedure on page 71.
Setting range:
Fixed/Variable
Normal Setting:
Fixed
This parameter enables you to specify the channel
on which the Clavinova transmits MIDI data.
See the procedure on page 71.
Setting for:
Main, Left, Layer, Left Layer
Setting range:
Midi/Usb1 Ch1 - Ch16, Off (Not transmitted.)
Normal setting:
Main — Midi/Usb1 Ch1
Left — Midi/Usb1 Ch2
Layer — Midi/Usb1 Ch3
Left Layer — Midi/Usb1 Ch4
You can specify whether each channel of data from
MIDI [IN] and USB [TO HOST] will be received.
See the procedure on page 71.
Setting for:
Midi/Usb1 Ch1 - Ch16
Usb2 Ch1 - 16
Setting range:
Song, Main, Left, Layer, LeftLayer, Keyboard, Off
Normal setting:
Midi/Usb1 Ch1- Ch16 Song
Usb2 Ch1 Keyboard
Usb2 Ch2 Main
Usb2 Ch3 Left
Usb2 Ch4 Layer
Usb2 Ch5 LeftLayer
Others Off
Selecting the AUX OUT level
[AuxOutLevel]
Setting the MIDI transmit channel
[MidiOutChannel]
B
D
NO YES
A
C
AuxOutLevel
Fixed
B
D
NO YES
A
C
MidiOutChannel
Main Midi/Usb1Ch1
Select a voice part. Specify the channel.
Setting the MIDI receive channel
[MidiInChannel]
B
D
NO YES
A
C
MidiInChannel
Midi/Usb1Ch1 Song
Select a channel Select a MIDI receive part
USB TO HOST
MIDI IN
Midi/Usb1
Ch1 - Ch16
Usb2
Ch1 - Ch16
Keyboard
– LeftLayer
Song
