77REFERENCE SECTION
Reference Section
MIDI IMPLEMENTATION CHART
KAWAI DIGITAL PIANO MODEL: CA1200, CA1000
DATE: DECEMBER 2001
VERSION 1.0
Mode 1: OMNI ON, POLY Mode 2: OMNI ON, MONO : Yes
Mode 3: OMNI OFF, POLY Mode 4: OMNI OFF, MONO : No
Function Transmit Receive Remarks
Basic Default 1 1
Channel Changes 1 – 16 1 – 16
Default 3 3
Mode Messages 1, 3*
Altered * * * * * * * * *
Note 15 – 113** 0–127
Number True voice * * * * * * * * * 15 – 113
Velocity Note ON 9nH v=1–127
Note OFF 9nH v=0
After Key’s ✕✕
Touch Ch’s ✕✕
Pitch Bend ✕✕
0, 32 ❍❍Bank Select
7 ✕❍Volume
11 ✕❍Expression pedal
64 (Right pedal) Sustain pedal
Control 66 (Center pedal) Sustenuto pedal
Change 67 (Left pedal) Soft pedal
Program 0 – 127 ***
Change :True # * * * * * * * * *
System Exclusive ❍❍On/Off Selectable
: Song Position ✕✕
Common : Song Select ✕✕
: Tune ✕✕
System : Clock ✕✕
Real Time : Commands ✕✕
Aux : Local On/Off ✕❍
: All Notes Off ✕❍ (123-127)
: Active Sense ❍❍
: Reset ✕✕
Notes ** The value depends on the Transpose setting.
* The default for the OMNI
mode is ON. Specifying
MIDI channels automatically
turns it OFF.
*** See the Program Change
Number Mapping in page
75.
