02: SPECTRUM
This is a type of filter that modifies the timbre by boosting or cutting the level
of specific frequencies. It is similar to an equalizer, but has eight frequency
points fixed at locations most useful for adding character to the sound.
fig.MFX02
03: ENHANCER
Controls the overtone structure of the high frequencies, adding sparkle and
brightness to the sound.
fig.MFX03
Parameter Value Description
Q
0.5, 1.0, 2.0,
4.0, 8.0
Simultaneously adjusts the width of
the adjusted ranges for all of the fre-
quency bands.
Pan L64–63R
Stereo location of the SPECTRUM
output
Level 0–127 Output level
Band 1 (250 Hz)
-15– +15 dB
Gain of each frequency band
* This can be set using the sliders of
the part mixer.
Band 2 (500 Hz) #1
Band 3 (1 kHz) #2
Band 4 (1.25 kHz)
Band 5 (2 kHz) #3
Band 6 (3.15 kHz)
Band 7 (4 kHz) #4
Band 8 (8kHz)
Spectrum
L out
R out
Pan R
Pan L
L in
R in
Parameter
Value Description
Sens #1
0–127 Sensitivity of the enhancer
Mixl #2 0–127
Level of the overtones generated by the en-
hancer
Low Gain -15– +15 dB
Gain of the low frequency range of fre-
quencies
High Gain -15– +15 dB
Gain of the high frequency range of fre-
quencies
Level 0–127 Output level
L in
R in
L out
R out
Mix
Mix
Enhancer
Enhancer
2-Band
EQ
2-Band
EQ
