62
43: MULTI TAP DELAY
This effect provides four delays. Each of the Delay Time parameters can be
set to a note length based on the selected tempo. You can also set the
panning and level of each delay sound.
fig.MFX43
HF Damp
200–8000
Hz, BYPASS
Adjusts the frequency above which sound
fed back to the effect is filtered out. If you
do not want to filter out any high frequen-
cies, set this parameter to BYPASS.
Balance
D100:0W–
D0:100W
Volume balance between the direct
sound (D) and the delay sound (W)
Level 0–127 Output level
Parameter
Value Description
Parameter Value Description
Delay 1–4
#1–#4
0–4000 ms,
note
Adjusts the time until Delays 1–4 are heard.
Pan 1–4 L64–63R Stereo location of Delays 1–4
Level 1–4 0–127 Output level of Delays 1–4
Feedback -98– +98 %
Adjusts the amount of the delay sound that’s fed
back into the effect. Negative (-) settings invert
the phase.
HF Damp
200–8000
Hz, BYPASS
Adjusts the frequency above which sound fed
back to the effect is filtered out. If you don’t want
to filter out any the high frequencies, set this pa-
rameter to BYPASS.
Low Gain -15– +15 dB Gain of the low frequency range
High Gain -15– +15 dB Gain of the high frequency range
Balance
D100:0W–
D0:100W
Volume balance between the direct sound (D)
and the effect sound (W)
Level 0–127 Output level
L in
R in
L out
R out
Multi Tap Delay
Balance W
Balance D
Balance W
Balance D
Delay 1
Delay 3
Delay 4
Delay 2
Feed
back
2-Band
EQ
2-Band
EQ
