42
13: RING MODULATOR
This is an effect that applies amplitude modulation (AM) to the input signal,
producing bell-like sounds. You can also change the modulation frequency
in response to changes in the volume of the sound sent into the effect.
fig.MFX13
Mix
0–127 Level of the phase-shifted sound
Low Gain -15– +15 dB Gain of the low frequency range
High Gain -15– +15 dB Gain of the high frequency range
Level 0–127 Output level
Parameter
Value Description
Parameter Value Description
Frequency #1
0–127
Adjusts the frequency at which modulation is ap-
plied.
Sens #2 0–127
Adjusts the amount of frequency modulation applied.
Polarity UP, DOWN
Determines whether the frequency modulation
moves towards higher frequencies (
UP
) or lower
frequencies (
DOWN
).
Low Gain -15– +15 dB Gain of the low frequency range
High Gain -15– +15 dB Gain of the high frequency range
Balance #3
D100:0W–
D0:100W
Volume balance between the direct sound (D)
and the effect sound (W)
Level 0–127 Output level
L in
R in
L out
R out
Ring Mod
2-Band EQ
2-Band EQ
Ring Mod
