46: TIME CONTROL DELAY
This lets you smoothly vary the delay time. As the delay time is varied, the
pitch will change correspondingly; lengthening the delay time will lower
the pitch, and shortening it will raise the pitch.
fig.MFX46
Low Gain
-15– +15 dB Gain of the low frequency range
High Gain -15– +15 dB Gain of the high frequency range
Balance #4
D100:0W–
D0:100W
Volume balance between the direct
sound (D) and the effect sound (W)
Level 0–127 Output level
Parameter
Value Description
Parameter Value Description
Delay #1
0–4000 ms, note Adjusts the time until the delay is heard.
Feedback #2 -98– +98 %
Adjusts the amount of the delay that’s fed
back into the effect. Negative (-) settings
invert the phase.
Acceleration #3 0–15
Adjusts the time over which the Delay
Time changes from the current setting to
a specified new setting.
The rate of change for the Delay Time di-
rectly affects the rate of pitch change.
HF Damp
200–8000 Hz,
BYPASS
Adjusts the frequency above which sound
fed back to the effect is filtered out. If you
do not want to filter out any high frequen-
cies, set this parameter to BYPASS.
Pan L64–63R Stereo location of the delay
Low Gain -15– +15 dB Gain of the low frequency range
High Gain -15– +15 dB Gain of the high frequency range
Balance #4
D100:0W–
D0:100W
Volume balance between the direct
sound (D) and the delay sound (W)
Level 0–127 Output level
L in
R in
L out
R out
2-Band
EQ
Balance W
Balance W
Balance D
Balance D
2-Band
EQ
Feedback
Time Control Delay
