57
36: FBK PITCH SHIFTER (Feedback Pitch Shifter)
This allows the pitch-shifted sound to be fed back into the effect.
fig.MFX36
Wow/Flutter Rate
0–127
Speed of wow/flutter (complex variation
in pitch caused by tape wear and rota-
tional irregularity)
Wow/Flutter
Depth
0–127 Depth of wow/flutter
Echo Level 0–127 Volume of the echo sound
Direct Level 0–127 Volume of the original sound
Parameter
Value Description
Parameter Value Description
Mode 1, 2, 3, 4, 5
Setting a higher value for this parameter re-
sults in a slower response, but steadier pitch.
Coarse #1
-24– +12
semi
Adjusts the pitch of the pitch-shifted sound in
semitone steps.
Fine
-100– +100
cent
Adjusts the pitch of the pitch-shifted sound in
2-cent steps.
Delay #2
0.0–2000 ms,
note
Adjusts the time until the pitch shifted sound is
heard.
Feedback #3 -98– +98 %
Adjusts the amount of the pitch-shifted sound
that’s fed back into the effect. Negative (-) set-
tings invert the phase.
Pan L64–63R Stereo location of the pitch-shifted sound
Low Gain -15– +15 dB Gain of the low frequency range
High Gain -15– +15 dB Gain of the high frequency range
Balance #4
D100:0W–
D0:100W
Volume balance between the direct sound (D)
and the pitch-shifted sound (W)
Level 0–127 Output level
L in
R in
L out
R out
2-Band
EQ
Balance W
Balance W
Balance D
Balance D
2-Band
EQ
Feedback
Pitch Shifter
