40: MODULATION DELAY
Adds modulation to the delayed sound.
When Feedback Mode is NORMAL:
fig.MFX40a
When Feedback Mode is CROSS:
fig.MFX40b
R in R out
L in L out
Feedback
Feedback
Balance W
Balance D
Balance W
Balance D
2-Band
EQ
2-Band
EQ
Delay
Delay
Modulation
Modulation
R in
R out
L in
L out
Feedback
Feedback
Balance W
Balance D
Balance W
Balance D
2-Band
EQ
2-Band
EQ
Delay
Delay
Modulation
Modulation
Parameter
Value Description
Feedback Mode
NORMAL,
CROSS
Selects the way in which delay sound is
fed back into the effect (See the figures
above.)
Delay Left #1
0–2000 ms,
note
Adjusts the time until the delay sound is
heard.
Delay Right #2
Feedback #3 -98– +98 %
Adjusts the amount of the delay sound
that’s fed back into the effect. Negative (-
) settings invert the phase.
HF Damp
200–8000 Hz,
BYPASS
Adjusts the frequency above which sound
fed back to the effect is filtered out. If you
don’t want to filter out any high frequen-
cies, set this parameter to BYPASS.
Rate #4
0.05–10.00 Hz,
note
Frequency of modulation
Depth 0–127 Depth of modulation
Phase 0-180 deg Spatial spread of the sound
Low Gain -15– +15 dB Gain of the low frequency range
High Gain -15– +15 dB Gain of the high frequency range
Balance
D100:0W–
D0:100W
Volume balance between the direct
sound (D) and the delay sound (W)
Level 0–127 Output level
