35: TAPE ECHO
A virtual tape echo that produces a realistic tape delay sound. This
simulates the tape echo section of a Roland RE-201 Space Echo.
fig.MFX35
Parameter
Value Description
Signal Distortion
0–127 Depth of distortion
Frequency Range
#1
0–127
Frequency response of the playback sys-
tem
Decreasing this value will produce the im-
pression of an old system with a poor fre-
quency response.
Disc Type #2 LP, EP, SP
Rotational speed of the turntable
This will affect the frequency of the scratch
noise.
Scratch
Noise Lev-
el
0–127
Amount of noise due to scratches on the
record
Dust Noise Level 0–127 Volume of noise due to dust on the record
Hiss Noise Level 0–127 Volume of continuous “hiss”
Total Noise Level
#3
0–127 Volume of overall noise
Wow 0–127 Depth of long-cycle rotational irregularity
Flutter 0–127 Depth of short-cycle rotational irregularity
Random 0–127
Depth of indefinite-cycle rotational irregu-
larity
Total Wow/
Flutter
#4
0–127 Depth of overall rotational irregularity
Balance
D100:0W–
D0:100W
Volume balance between the direct
sound (D) and the effect sound (W)
Level 0–127 Output level
Parameter
Value Description
Mode #1
S, M, L, S+M,
S+L, M+L,
S+M+L
Combination of playback heads to use
Select from three different heads with dif-
ferent delay times.
S:
short
M:
middle
L:
long
Repeat Rate #2 0–127
Tape speed
Increasing this value will shorten the spac-
ing of the delayed sounds.
Intensity #3 0–127 Amount of delay repeats
Bass -15– +15
Boost/cut for the lower range of the echo
sound
Treble -15– +15
Boost/cut for the upper range of the echo
sound
Head S Pan
L64–63R
Independent panning for the short, mid-
dle, and long playback heads
Head M Pan
Head L Pan
Tape Distortion 0–5
Amount of tape-dependent distortion to
be added
This simulates the slight tonal changes that
can be detected by signal-analysis equip-
ment. Increasing this value will increase
the distortion.
Echo Level
Echo Level
L in
R in
L out
R out
Tape Echo
Direct Level
Direct Level
