37: 2Vo PITCH SHIFTER (2-Voice Pitch Shifter)
Shifts the pitch of the original sound. This 2-voice pitch shifter has two pitch
shifters, and can add two pitch-shifted versions of the original sound.
fig.MFX37
38: GATED REVERB
This is a special type of reverb in which the reverb is cut off without being
allowed to decay naturally.
fig.MFX38
Parameter
Value Description
Mode
1, 2, 3, 4, 5
Setting a higher value for this parameter
results in a slower response, but steadier
pitch.
Coarse A #1
-24– +12
semi
Adjusts the pitch of Pitch Shift A/B in
semitone steps.
Coarse B #2
Fine A
-100–
+100 cent
Adjusts the pitch of Pitch Shift A/B in 2-
cent steps.
Fine B
Delay A #3
0.0–2000 ms,
note
Adjusts the time until Pitch Shift A/B is
heard.
Delay B #4
Pan A
L64–63R Stereo location of Pitch Shift A/B
Pan B
Level A
A100:0B–
A0:100B
Volume balance between Pitch Shift A
and Pitch Shift B
Level B
Balance
D100:0W–
D0:100W
Volume balance between the direct
sound (D) and the pitch shifted sound (W)
Level 0–127 Output level
L in
R in
L out
R out
2Voice Pitch Shifter
Level Balance A
Balance W
Balance D
Balance W
Balance D
Level Balance B
PanB R
PanA L
PanA R
PanB L
Parameter Value Description
Type #1
NORMAL, RE-
VERSE
Type of reverb
NORMAL:
conventional gated reverb
REVERSE:
backwards reverb
Pre Delay #2 0.0–100.0 ms
Adjusts the time until the reverb sound is
heard.
Time #3 5–500 ms
Adjusts the time from when the reverb is
first heard until it disappears.
Pan L64–63R Stereo location of Pitch Shift
Low Gain -15– +15 dB Gain of the low frequency range
High Gain -15– +15 dB Gain of the high frequency range
Balance #4
D100:0W–
D0:100W
Volume balance between the direct
sound (D) and the reverb sound (W)
Level 0–127 Output level
L in
R in
L out
R out
Gated Reverb
2-Band
EQ
Balance W
Balance W
Balance D
Balance D
2-Band
EQ
