Driver Installation and Settings
Steps to be performed on the UA-25EX itself are marked by a
symbol.
Do not connect the UA-25EX to your computer until you are directed to do so.
1
Start up Windows without the UA-25EX connected.
* Disconnect all USB cables other than those for a USB keyboard and/or USB mouse (if used).
2
Close all currently running software.
3
Insert the included “UA-25EX Driver CD-ROM” into your CD-ROM drive.
4
In the CD-ROM, navigate to the Driver ➝ XP folder, and double-click the Setup icon.
*If the “Install Program As Other User” dialog box appears, click [Cancel] to terminate the
installation, log on to Windows using an administrator account, and perform the installation
once again.
5
The screen will indicate “UA-25EX Driver will be installed on your computer.” Click [Next].
* If any other message appears, proceed as directed by the message.
6
To begin the installation, click [Next].
If the Software Installation dialog box appears, click [Continue Anyway] to proceed with the
installation.
fig.XP-6e.eps
* If you are unable to proceed, click [OK] to halt the installation, and then change the settings as
described in “Driver signing option settings (Windows XP)” (p. 39).
The screen will indicate “Ready to install the driver.”
* If any other message appears, proceed as directed by the message.
Windows XP users
Installing the driver
Operation of the UA-25EX
