Effects Parameters
188
Appendix
REVERB HALL, REVERB ROOM, REVERB STAGE, REVERB PLATE
EARLY REF.
GATE REVERB, REVERSE GATE
Parameter Range Description
REV TIME 0.3 – 99.0 s Reverb time
INI.DLY 0.0 – 500.0 ms Initial delay before reverb begins
HI.RATIO 0.1 – 1.0 High-frequency reverb time ratio
LO.RATIO 0.1 – 2.4 Low-frequency reverb time ratio
DIFF. 0 – 10 Reverb diffusion (left–right reverb spread)
DENSITY 0 – 100% Reverb density
E/R DLY 0.0 – 100.0 ms Delay between early reflections and reverb
E/R BAL. 0 – 100% Balance of early reflections and reverb (0% = ER, 100% = reverb)
HPF Thru, 21.2 Hz – 8.0 kHz High-pass filter cutoff frequency
LPF 50 Hz – 16.0 kHz, Thru Low-pass filter cutoff frequency
GATE LVL OFF, –60 to 0 dB Level at which gate kicks in
ATTACK 0 – 120 ms Gate opening speed
HOLD 0.02 ms – 2.13 s Gate open time
DECAY 6.0 ms – 46.0 s Gate closing speed
MIX BAL. 0 – 100 [%] Mix balance of the effects and dry sounds
Parameter Range Description
TYPE S-Hall, L-Hall, Random,
Revers, Plate, Spring
Type of early reflection simulation
ROOMSIZE 0.1 – 20.0 Reflection spacing
LIVENESS 0 – 10 Early reflections decay characteristics (0 = dead, 10 = live)
INI.DLY 0.0 – 500.0 ms Initial delay before reverb begins
DIFF. 0 – 10 Reverb diffusion (left–right reverb spread)
DENSITY 0 – 100% Reverb density
ER NUM. 1 – 19 Number of early reflections
FB.GAIN –99 to +99% Feedback gain
HI.RATIO 0.1 – 1.0 High-frequency feedback ratio
HPF Thru, 21.2 Hz – 8.0 kHz High-pass filter cutoff frequency
LPF 50 Hz – 16.0 kHz, Thru Low-pass filter cutoff frequency
MIX BAL. 0 – 100 [%] Mix balance of the effects and dry sounds
Parameter Range Description
TYPE Type-A, Type-B Type of early reflection simulation
ROOMSIZE 0.1 – 20.0 Reflection spacing
LIVENESS 0 – 10 Early reflections decay characteristics (0 = dead, 10 = live)
INI.DLY 0.0 – 500.0 ms Initial delay before reverb begins
DIFF. 0 – 10 Reverb diffusion (left–right reverb spread)
DENSITY 0 – 100% Reverb density
ER NUM. 1 – 19 Number of early reflections
FB.GAIN –99 to +99% Feedback gain
HI.RATIO 0.1 – 1.0 High-frequency feedback ratio
HPF Thru, 21.2 Hz – 8.0 kHz High-pass filter cutoff frequency
LPF 50 Hz – 16.0 kHz, Thru Low-pass filter cutoff frequency
MIX BAL. 0 – 100 [%] Mix balance of the effects and dry sounds
