34
Basics Section
The Drum Voices are stored in separate areas of the
User and GM/XG memory sections.
•To call up the User Drum memory (USDR1/
USDR2):
Press the [USER] button while holding down the
[DRUM] button.
•To call up the GM/XG Drum memory
•To call up the XG SFX Kit memory
Press the [GM/XG] button while holding down the
[DRUM] button.
n PRESET, of course, contains the Preset Voices. The XG
Voices are assigned in order according to the GM format,
starting with Bank 1, and various XG Voices are
distributed throughout the GM/XG memory banks.
USER is stored in internal RAM memory and contains
factory default Voices. These can be overwritten, but can
be recalled from the original factory settings at any time
if required.
3 Select a Voice number.
Selecting with the [INC/YES] and
[DEC/NO] buttons
First, press the [ENTER] button to specify the Voice
Memory, then press the [INC/YES] button to
increment the Voice Number, and press [DEC/NO] to
decrement it.
Selecting with the numeric keypad
and [ENTER] button
First, specify the Voice number with the numeric
keypad, then press the [ENTER] button to actually set
it. For example, to select voice number 100, press
buttons [1], [0] and [0] in order. (The indicated
number flashes.) Finally, press the [ENTER] button to
select the Voice.
n For one- or two-digit numbers, it’s not necessary to enter
all three digits (such as, “001” or “010”). For example, to
enter Voice number “3,” simply press numeric keypad
button [3], then press the [ENTER] button.
CATEGORY
SEARCH
PRESET
USER
GM XG
SE
OTHER
DRUM/PERC
XG Drum 1~20
User Drum
1/2
DATA
DEC INCNO YES
5
PIANO
BASS
1
0
23
46
789
REED/PIPE
STRINGS
SYN LEAD
BRASS
ENTER
SYN PAD
ORGAN GUITAR
KEYBOARD
SYN COMP
CHROMATIC
PERCUSSION
Set the number.Specify the number.
KEYELEMPAR T
OCTAVE
PAG E
1
2
3
4
GrandPno
XG100
The displayed value flashes.
