48
Basics Section
Common Edit and Editing Individual
Elements
Voices can consist of up to four Elements (page 26).
Use Common Edit to edit the settings common to all
four Elements. The Voice Edit mode can be divided
into screens for Common Edit and those for editing
each Element. In the Voice Edit mode,
simultaneously press both the [–] and [+] buttons to
switch between the Common Edit screens and the
screens for editing each Element.
Common Edit screens
Element Edit screens
Switching Elements On/Off (Mute)
In Voice Edit Mode, an Element can be switched on/
off temporarily when you press the [MUTE] button.
The Element indicator which is muted will flash.
This lets you mute other Elements in the Voice so
that you can listen to the changes to the Element
that you are editing.
Switching Between Screens and Entering
Settings
After selecting a Common Edit screen or an edit
screen for an Element (1 to 4), press the [▲] and [▼]
buttons to switch to other screens.
The S03 has a huge variety of available parameters.
As you change the display pages, an arrow mark on
the right side of the display points to the parameter
chart printed on the panel, indicating the parameter
type and what aspect of the instrument it’s related
to.
Use the INC/YES and DEC/NO buttons to set each
parameter value.
Some parameters have multiple “pages,” indicated
by a special arrow mark (“fi”) in the top right of the
LCD (see below). Use the [E]/[F] buttons to
select these pages.
GrandPno
KEYELEMPAR T
OCTAVE
PAG E
Name
1 E
Common indicator
Element SW
KEYELEMPAR T
OCTAVE
PAG E
on
1 E 1
Element indicator
PART ELEMENT KEY
MUTE
COMMON
PART ELEMENT KEY
MUTE
COMMON
KEYELEMPAR T
OCTAVE
PAG E
1 E
DATA
DEC INCNO YES
Page
KEYELEMPA RT
OCTAVE
PAG E
3 E
VOICE
MIX
TONE
EFFECT
CONTROLLER
GENERAL
OSC MIX
PITCH
AMP
EFFECT
LFO
FILTER
Level
100
KEYELEMPAR T
OCTAVE
PAG E
3 E
DATA
DEC INCNO YES
Level
101
KEYELEMPAR T
OCTAVE
PAG E
5 E 1
KEYELEMPAR T
OCTAVE
PAG E
5 E 1
DATA
DEC INCNO YES
NtLmt-L
C-2
NtLmt-H
G8
