75
Voice Mode
9-1. PEGAtkR (PEG Attack Rate)
9-2. PEGDcy1R (PEG Decay 1 Rate)
9-3. PEGDcy2R (PEG Decay 2 Rate)
9-4. PEGRelR (PEG Release Rate)
You can set various Rate parameters (the time it takes
for the pitch to change from one level to the next) for
the Pitch Envelope Generator (PEG). Combined with
the PEG Level settings below, these can be used control
the change in sound from the moment a note is pressed
on the keyboard to the moment it is released (see
illustration below). You can set different values for
each Element.
❏
Settings: 0~63
10-1. PEGInitL (PEG Initial Level)
10-2. PEGAtkL (PEG Attack Level)
10-3.
PEGDcy1L (PEG Decay 1 Level)
10-4. PEGSusL (PEG Sustain Level)
10-5. PEGRelL (PEG Release Level)
You can set various Level parameters for the Pitch
Envelope Generator (PEG). Combined with the Rate
settings above (PEG Atk/Dcy 1/Dcy 2/Rel R), these
can be used control the change in sound from the
moment a note is pressed on the keyboard to the
moment it is released (see illustration below). You can
set different values for each Element.
❏
Settings: –2400~+2400
Pitch Envelope Generator Settings
You can set four Rate parameters (which control
how fast the pitch changes from one Level to the
next) and five Level (pitch) parameters, which
control the change in pitch from the moment you
press a note on the keyboard to the moment you
release it. The Initial Level and Attack Rate settings
determines from what pitch the note starts when it
is played and the time it takes to reach the Attack
Level pitch setting. The Decay 1 and 2 Rates control
how long it takes for the pitch to reach the Decay 1
and 2 Levels, respectively. Finally, the Release Rate
and Release Level parameters determine the final
pitch that the sound goes to when a key is released
and how long it takes to reach that pitch.
In the illustration, the letters a - d indicate the
respective Rate (R) settings for Attack - Release.
The greater the value for each Rate, the faster the
pitch goes to the next set Level — in other words, the
time it takes for the pitch to change (between Level
settings) becomes shorter. Velocity Sensitivity and
other parameters can also be set if required.
PEGAtkR
KEYELEMPAR T
OCTAVE
PAG E
C3
9 E 1
PEGDcy1R
KEYELEMPAR T
OCTAVE
PAG E
00
9 E 1
PEGDcy2R
KEYELEMPAR T
OCTAVE
PAG E
00
9 E 1
PEGRelR
KEYELEMPAR T
OCTAVE
PAG E
00
9 E 1
PEGInitL
KEYELEMPAR T
OCTAVE
PAG E
+0000
10 E 1
PEGAtkL
KEYELEMPAR T
OCTAVE
PAG E
+0000
10 E 1
PEGDcy1L
KEYELEMPAR T
OCTAVE
PAG E
+0000
10 E 1
PEGSusL
KEYELEMPAR T
OCTAVE
PAG E
+0000
10 E 1
PEGRelL
KEYELEMPAR T
OCTAVE
PAG E
+0000
10 E 1
0
Release
Level
Attack
Level
Attack
Time
Initial
Level
Decay1
Time
Decay2
Time
Release
Time
a
b
c
d
Decay1
Level
Sustain
Level Key off
Time
Pitch
Element Pitch
