Appendix
Harmonic Content (Control #071)
Messages which adjust the filter resonance set for each
voice.
The value set here is an offset value which will be added
to or subtracted from the voice data.
Higher values will result in a more characteristic,
resonant sound.
Depending on the voice, the effective range may be
narrower than the range available for adjustment.
Release Time (Control #072)
Messages which adjust the EG release time set for each
voice.
The value set here is an offset value which will be added
to or subtracted from the voice data.
Attack Time (Control #073)
Messages which adjust the EG attack time set for each
voice.
The value set here is an offset value which will be added
to or subtracted from the voice data.
Brightness (Control #074)
Messages which adjust the filter cutoff frequency set for
each voice.
The value set here is an offset value which will be added
to or subtracted from the voice data.
Lower values will result in a softer sound.
Depending on the voice, the effective range may be
narrower than the range available for adjustment.
Portamento Control (Control #084)
Messages which apply a portamento between the
currently-sounding note and the subsequent note.
Portamento Control is transmitted specifying the note-on
key of the currently-sounding note.
Specify a Portamento Source Key number between 0 -
127.
When a Portamento Control message is received, the
currently sounding pitch will change with a Portamento
Time of 0 to the next note-on key on the same channel.
For example, the following settings would apply a
portamento from note C3 to C4.
90H 3CH 7FH......... C3 Note on
B0H 54H 3CH.........Source key number set to C3
90H 48H 7FH.......... C4 Note on (When C4 is on, C3 is
raised by a portamento to C4.)
Effect1 Depth (Reverb Send Level)
(Control #091)
Messages which adjust the send level for the Reverb
effect.
Effect3 Depth (Chorus Send Level)
(Control #093)
Messages which adjust the send level for the Chorus
effect.
Effect4 Depth (Variation Effect Send Level)
(Control #094)
Messages which adjust the send level for the Variation
effect.
If Variation effect uses System effect, this message sets
the send level for the Variation effect. If it uses Insertion
effect, this setting is invalid.
Data Increment (Control #096)
Decrement (Control #097) for RPN
Messages which increase or decrease the MSB value of
pitch bend sensitivity, fine tune, or coarse tune in steps of
1. You are required to assign one of those parameters
using the RPN in the external device in advance.
The data byte is ignored.
When the maximum value or minimum value is reached,
the value will not be incremented or decremented further.
(Incrementing the fine tune will not cause the coarse
tune to be incremented.)
NRPN (Non-Registered Parameter Number)
LSB (Control #098)
NRPN (Non-Registered Parameter Number)
MSB (Control #099)
Messages which adjust a voice’s vibrato, filter, EG, drum
setup or other parameter settings.
First send the NRPN MSB and NRPN LSB to specify the
parameter which is to be controlled. Then use Data Entry
(page 96) to set the value of the specified parameter.
Note that once the NRPN has been set for a channel,
subsequent data entry will be recognized as the same
NRPN’s value change. Therefore, after you use the
NRPN, you should set a Null (7FH, 7FH) value to avoid
an unexpected result.
The following NRPN numbers can be received.
*rr=Note number for each drum voice instrument.
PARAMETER
Vibrato Rate
Vibrato Depth
Vibrato Delay
Filter Cutoff Frequency
Filter Resonance
EG Attack Time
EG Decay Time
EG Release Time
Drum Filter Cutoff Frequency
Drum Filter Resonance
Drum EG Attack Rate
Drum EG Decay Rate
Drum Instrument Pitch Coarse
Drum Instrument Pitch Fine
Drum Instrument Level
Drum Instrument Panpot
Drum Instrument Reverb Send Level
Drum Instrument Chorus Send Level
Drum Instrument Variation Send Level
NRPN MSB NRPN LSB
01 08
01 09
01 0A
01 20
01 21
01 63
01 64
01 66
14 rr
15 rr
16 rr
17 rr
18 rr
19 rr
1A rr
1C rr
1D rr
1E rr
1F rr
