53
Quick Start
Playing with a CD, Tape, or MD (Using MIX IN Jack)
Using the TD-6’s MIX IN jack allows you to play along with a CD or other
external audio sources.
1
Make the connections as shown in the following figure.
fig.Q-027.e
2
When you begin playback of the CD deck or other device, the
performance is then audible through the headphones, audio
equipment, amp, or other device.
To prevent malfunction
and/or damage to
speakers or other devices,
always turn down the
volume, and turn off the
power on all devices
b
efore making any
connections.
TD-6
Headphones,
audio equipment, amp, etc.
CD/MD deck,
cassette player, etc.
MIX IN jack
OUTPUT jack
Stereo miniature phone type
Use the plug that
matches the device
you are listening with.
Adjust the volume level of
the playback device when
correcting the volume
b
alance between the CD or
other sound input and the
drum kit.
