15 − Appendix
TASCAM 2488neo 105
Effect parameter change MIDI messages
Use the following MIDI channels to send messages to the
2488neo effects (see “Effects“ on page 39):
Channels 1 through 8 are used for mic effects. The Bank
Select controller is used with channel 14 to choose which
group of eight channels or inputs is affected.
Bank 0: Mixer channels 1 though 8
Bank 1: Mixer channels 9 through 16
Bank 2: Mixer channels 17 through 24
Bank 3: Inputs A through H
Channel 9 is used to control the stereo dynamics processor effect.
Channel 10 is used to control the single effect.
Channel 11 is used to control the multi-effect.
The way in which the effects are controlled is by the use of
NRPN (non-Registered Parameters).
Controller 98 is used for the LSB of each NRPN, and con-
troller 99 for the MSB.
In effect settings where more than one effect may be
selected, the same NRPN may produce a different out-
come, depending on the selected effect.
NOTE
All values, etc. listed in these tables are in decimal notation.
ª
Example effect parameter change
This example shows the MIDI bytes (in hexadecimal nota-
tion) needed to set the ratio of a compressor effect on mixer
channel 9.
Note how Control Changes 6 and 38 (decimal) are used for
data entry.
Control Changes 96 and 97 (decimal) are used for incre-
ment and decrement as well.
MIDI message
(hexadecimal)
Meaning
BD 00 01 Sends a Control Change 0 (Bank Select)
message on channel 14 to select bank 1
B0 63 00 Sends NPRN MSB to 2nd channel in group
(mixer channel 9) on MIDI channel 1
B0 62 01 Sends 1 as NPRN LSB to 2nd channel in
group, which controls the ratio when
compressor is selected as mic effect
B0 06 00 Data entry Control Change LSB on MIDI
channel 1
B0 26 00 Data entry Control Change MSB on MIDI
channel 1
The ratio of the compressor on mixer channel 9 is now set
to a value of 0.
