CHAPTER 1: Getting Started
7
A Touch screen
→ pg. 3 “Tapping with the stylus pen” in “Quick
Guide”.
B Charge indicator (amber)
Lights up when the Pocket Controller is being
charged. The indicator goes out when charging is
completed.
C VOLUME –/+ buttons
Adjust the overall volume.
D STOP, ON/STANDBY button
Stops playback, and turns the Pocket Controller on/
off.
E Select button
Executes the selected operation.
F I/O port
Accepts the terminal on the cradle.
G Cursor buttons
Selects the item on the touch screen or move the slider
on a control bar.
H AC adapter jack
Accepts the AC adaptor.
I PLAY button
Starts playback.
J (Song Select, Fast Reverse/Fast
Forward) buttons
Pressing the button selects a song.
Holding down the button fast reverses/forwards.
K (Back) button
Returns to the previous screen.
L Screen protector
Open or remove the protector when you tap on the
touch screen. To remove the screen protector, lift it up
and fold it back until it comes off.
M Keyboard
Enters characters. (→ pg. 33 “Entering Characters”)
PLAYSTOP
ON/STANDBY
VOLUME
T
R
E
W
Q
G
F
D
P
O
I
U
Y
L
K
J
H
A
S
V
C
X
Z
.
, ,
M
N
B
5
%
4
$
3
#
2
@
1
0
9
8
7
6
!
Del
(
∗
&
.
. .
)
=
~
+
–
–
/?
Tab
Fn
Space
Symbol
Paste
N
um
C
ut
Copy
Caps
` "
>
<
Poc
k
et Contro
ll
er
— Front —
/
